Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
LIDA
Model Number:
Use:
Hotel, House, Office, Villa
Key words:
Qatar container house portacabins labor camp
Main frame:
3.5mm cold form Steel
Wall and roof:
75mm Galvanized Color Steel
Floor:
18mm Plywood + PVC floor Leather
Supply Ability
Supply Ability:
300 Unit/Units per Month
20ft container building a for sale
Company Information
Our Weifang Henglida Steel Structure Co.,Ltd.( Lida Group) is one of the largest manufacturers of the prefabricated house, Flat Pack modulr 20ft container building a for sale, LGS steel villas, and steel structure warehouse in China. We have been doing well in this field for more than 21 years, and we have exported our products to more than 90 countries as well as our domestic market with ISO9001, CE and SGS approval.Lida Group is a supplier of the series products for











Our big family:







Product Description









 General technical description for Prefabricated Modular Container House

 Technical Parameter:

Size: GP20, GP40 and HP40
Wind Resistance: Grade 12
Wall permitted loading: 0.6KN/ m2
Ceiling Permitted live loading: 0.5 KN/m2
Wall Coefficient of thermal conductivity: K=0.442W/mk
Ceiling Coefficient of thermal conductivity: K=0.55W/ m2K
You are so welcome to send us inquiries!



Dimensions and Weight

Inner length /external length :5.81m/6.06m



Inner width /external width: 2.188m/2.438m



Inner height/external height:2,410m/2.591m



Weight: 2000kg per unit

Steel framework



 Material: steel material Q234, thickness: 3.5mm,for top beam frame. Base beam frame and column.



Surface working: epoxy painting,two bottom and two surface.



Fittings: 8 standard container corner mould fittings PVC standard rainwater pipe



Forklift openings: size 100*250mm, distance is 1200mm



Floor

External wainscot: Flat galvanized color steel sheet, 0.5mm thickness



Floor structure: Girder made of 3.5mm steel. The purlin is C section steel. dimension 60x40x1.5mm.



Warm proof Insulation layer: 75mm rock wool



18mm  plywood



1.5mm PVC floor leather for living rooms floor;





 Ceiling

Construction:



Roof exterior layer: 1.2mm steel plate with epoxy painting



Warm proof insulation filling: 75mm rockwool between C section purlins;



Inner wainscot: 8mm OSB board with 12mm PVC decoration board.



Roof water drain: 4 PVC rainwater pipes in the corner pillars, diameter 50mm



Walls

Panel width: 1150mm; panel total thickness: 75mm, five panels fit into the long side and two panels fit into the short side.



Construction:



Common room wall: 75mm rockwool 0.4/0.4mm Galvanized



steel on both side , Desity of Rockwool: 120Kg/m3

Galvanize window opening on the wall if needed.

Door





External door: Insulated with opening dimension 950*2100mm, furnished with lock



with 3keys. Inner door: Insulated steel door.

Windows

Window material: PVC window with fly screen. 5mm glass.





Electrical fittings option

Electrical wire, 2.5mm2 for lighting system, and 4mm2 for AC units.



Main outlet and input industrial socket with 32A.



3 pcs 16A five hole universal socket.



2 pc double tube fluorescent lamp, 220V,50-60HZ



1 pc Single Switch, Honyar brand, with junction box



1 pc Electrical distribution box, box+breakers+earth leakage protective device



Optional Water system fittings

Water drain pipe, PPR pipe, dim 16-20mm, connection fittings are made of copper, life span over 10 years.



Exhaust fan or air exchange hole, size 250mm*250mm made of steel or PVC





Sanitary ware:



Western Close tool: ceramic, with pipes and installation fittings



Urinal: ceramic, with pipes and installation fittings



Wash basin: ceramic, with post, faucet, pipes and installation fittings



Shower head, Shower base, Water mixture





Our Services

 1. Professional design and engineering team: Full solution for site camp design. We could make the design for whole camp as per your requirement.



 2. Procurement and Manufacture for all material for prefabricated building. We have a professional procurement team to make sure all the materials are with good quality. And our factory operation under ISO standard, to make sure the fabrication works with high technology.



3. Site management & Installation supervision, We could send our engineers to help for the installation supervision, you just need to prepare a team which know normal construction works will be OK.


FAQ

Why Choose Container for Site Camp Solution? There are many advantages to modular camp construction for site camps including:

1) Good ability to assemble and disassemble for several times without damage.
2) Could be lifted, fixed and combined freely.
3) Heatproof and waterproof.
4) Cost saving and convenient transportation (Each 4 modulr 20ft container building a for sale can loaded in one standard container)
5) Service life can reach up to 15 - 20 years
6) We can provide the service of installation, supervision and training by extra.


Company Information



Our Weifang Henglida Steel Structure Co.,Ltd.( Lida Group)  is one of the largest manufacturers of the prefabricated house, Flat Pack modulr 20ft container building a for sale, steel villas, and steel structure warehouse in China. We have been doing well in this field for more than 20 years, and we have exported our products to more than 96 countries as well as our domestic market  with  ISO9001, CE and SGS approval.



We would like to give fully support for your further inquiry!

Best regards
Steven Chen
---------------------------------------------------------
Weifang Henglida Steel Structure Co., Ltd.
Add: Room1102, Unit B, Zhonghui Commercial Building,Qingdao,266000,China
Tel: 0086-532-88966982    Fax: 0086-532-88965571
Moble: KSA: 00966-548943324 China: 0086-13869829462

Qatar modulr 20ft container building a for sale portacabins labor camp





The product is well known as it can enhance the beauty and elegance of the building, widely used to build homes and commercial settings. It is able to undergo extremely high and cold temperatures. The product greatly helps people reduce the loss of unexpected calamity accident such as hurricanes or flood and costly repairs in the future. It is able to undergo extremely high and cold temperatures.
