Company Advantages
1. The appealing design of Lida Group allows customers to enjoy the aesthetics. Its coated steel materials make it highly corrosive
2. This product will provide enough ease and comfort for wearers instead of bringing extreme tightness or looseness problems that could bring down wearers' confidence. This product has been widely used in offices, meeting rooms, dormitories, shops, booths, etc
3. The product has great chemical resistance. It can protect against chemical attack or solvent reaction. It has resistivity to corrosive environments. This product features level A fire protection grade
4. The product has the advantages of fire resistance. Its structural elements have adequate resistance to overcome flames and spreading of fire. Constructed from environmentally friendly materials, the product can be recycled
5. Being frost resistant, the product can resist freezing or melting. When frozen, it does not lose its strength and become brittle. This product has been designed to last for decades

Overview

Quick Details

Place of Origin:: Shandong, China

Brand Name:: LIDA

Model Number:: LD-C036

Use:: Carport, Hotel, House, Kiosk,Booth, Office, Sentry Box,Guard House, Shop, Toilet, Villa, Warehouse, Workshop,Plant, modular building

Item:: Prefab container house, shipping container house, container home

Keywords:: flat pack container house prefabricated

Size:: ISO standard 20ft, 40ft are available

Storey:: 1 or 2 or 3 storey are available

Type:: flat pack container and shipping container

Loading:: SOC or loaded in 40ft HQ shipping container

Service life:: flat pack is 20 years, shipping container is 50 years

Fireproof:: resistant 3-4 hours

Waterproof:: new technology to provide good waterproof performance

Installation:: supervisor guiding, installation video are available

Supply Ability

Supply Ability:: 800 Unit/Units per Month container home

Product Description

small steel frame flat pack container house prefabricated new zealand

New zealand small steel frame flat pack container house prefabricated
Specification	1) 20ft: 605524352896mm
	2) 40ft: 1219224352896mm
	3) Roof Type: Flat roof with organized internal water draining design
	4) Storey: ≤3
Design parameter	1) Life span: up to 20years
	2) Floor Live load: 2.0KN/m2
	3) Roof Live load: 0.5KN/m2
	4) Wind load: 0.6KN/m2
	5) Earthquake-resistance: Grade 8, Fire-proof: Grade 4
Wall panel	1) Thickness: 75mm fiber glass sandwich panel, effective width: 1150mm
	2) Exterior steel sheet (standard configuration): Corrugated 0.4mm Aluminum-zinc color steel sheet, PE finishing coat, Color: white, Aluminum-zinc thickness≥40g/m2
	3) Insulation layer (standard configuration): 75mm Fiber glass, density≥50kg/m3, Fire-proof standard: grade A non-flambable
	4) Interior steel sheet(standard configuration): Flat 0.4mm Aluminum-zinc color steel sheet, PE finishing coat, Color: white, Aluminum-Zinc thickness≥40g/m2
Roof system	1) Steel frame & accessories: Main roof frame: cold formed steel, thickness=2.5mm, galvanized. with 4pcs galvanized lifting corners. Roof purlin: C804015*2.0, galvanized. Q235B steel
	2) Roof panel: 0.4 or 0.5mm thickness Aluminum-zinc color steel sheet, PE finishing coat. Color: white, Aluminum thickness≥70g/m2, 360° full connection
	3) Insulation: 100mm thickness Fiber glass with aluminum foil, Density=14kg/m3, Grade A fire-proof, nonflammable.
	4) Ceiling board: V-170 type, 0.5mm Aluminum-zinc color steel sheet, PE finishing coat. Color: white, Aluminum-zinc thickness≥40g/m2.
	5) Industrial socket: Fixed in explosion-proof box at the top beam of the short side, with 1 main power plug for power connection between containers
Corner pillar	1) Cold rolled steel: 4pcs pillar with same dimension, thickness=3mm, steel grade Q235B.
Corner pillar	2) Corner pillar and main frame are joined by hexagon socket head bolt, strength: grade 8.8. Filled with Fiberglass insulation
Floor System	1) Steel structure & accessories: Main floor frame: cold formed steel, thickness 3.5mm, galvanization; Floor purlin:C1204015*2.0, galvanized. Q235B steel. Standard container is Without forklift hole, it can be added according to customer's requirement.
	2) Insulation (optional): 100mm thickness Fiber glass with aluminum foil, Density=14kg/m3. Flammability:grade A, nonflammable.
	3) Bottom covering (optional): 0.25mm color steel sheet, Zinc thickness≥70g/m2.
	4) Floor board: 18mm thickness fiber cement board, Fire-proof:grade B1. Density≥1.3g/cm3
	5) Interior Flooring: 1.5mm thickness PVC leather, Blue marble color
Door & Window	1) Insulated light steel door: Entrance door is W850H2030mm, Toilet door is W700H2030mm.
Door & Window	2) PVC sliding window, double glass 5mm thickness, with mosquito screen and security bar. Standard window: W800H1100mm(for 2.4meter's container), W1130H1100mm(for 3 meter's container), Toilet window: W800*H500mm
Electric system	1) Rated power: 5.0 KW, suggestion external power source ≤3 in series.
	2) Technical parameters: CEE industrial plug, socket voltage 220V- 250V, 2P32A, Fixed in explosion-proof box at the top beam of the short side, the electric cable in the roof is protected by PVC pipe with CE certification; Using IP44 standard power distribution box.
	3) Electrical data: main power cable is 6 mm2, AC cable is 4 mm2, socket cable is 2.5 mm2, lighting & switch cable is 1.5 mm2. Five sockets, 1pc AC socket of 3holes 16A, 4pcs socket of 5holes 10A. 1pc single connection switch, 2pcs double tube LED light, 2*15W.
Painting	1) Primer painting: epoxy primer, Zinc color, thickness: 20 - 40 μm.
Painting	2) Finishing paint: Polyurethane finishing coat, white color, thickness: 40-50 μm. Total paint film thickness≥80μm. Galvanized components, galvanized layer thickness≥10μm (≥80g/m2)
