Budget-Friendly Modular House for Disaster Relief - Lightweight & Portable - Lida Group
INTRODUCTION OF CONTAINER HOUSE
Lida Folding Container House
Characteristics of Lida Folding Container House
Technical Parameter of Lida Folding Container House( Foldable Container House)
(1).Size: GP20, GP40 and HQ40
(2).Wind Resistance: Grade 12
(3).Wall permitted loading: 0.6KN/ m2
(4).Ceiling Permitted live loading: 0.5 KN/m2
(5).Wall Coefficient of thermal conductivity: K=0.442W/mk
(6).Ceiling Coefficient of thermal conductivity: K=0.55W/ m2K
Technical Parameter of Lida Folding Container House
3.3) Floor System of Lida Folding Container House( Foldable Container House)
Floor layer | 18mm cement silicon calcium board |
Floor Covering | PVC floor leather, the wear-resistant layer is 0.07mm. |
Load Capacity | A1 class fireproof, 18mm thick density 1.75-1.95g/cm3; high strength floor. |
Cushioning cushion | Industrial felt, cushioning, sound insulation, sealing, shockproof. |
Sealant sea | l High density polyurethane foam is used to completely seal waterproof, moisture-proof and noise reduction. |
3.4) Roof System of Lida Folding Container House( Foldable Container House)
TYPE | SPECIFICATION MODEL |
Roof material | Choose 6 2870 mm *950mm*50mm* double sided 4mm EPS board, cleaning plate, rivet. |
Support force | The 30mm*30mm*3mm angle iron is selected to directly weld the top frame and the 100mm*50mm*2.8mm*3000mm galvanized square tube is used as the supporting beam. |
Top waterproof | 7mm*1000mm*6000mm galvanized coiling machine is used for mechanical interlocking. The rivet and 995 structural adhesive are all sealed around. |
3.5) Exterior Wall System of Lida Folding Container House( Foldable Container House)
Outer Wall Thickness | 50mm silicon rock board, A class a fire protection and |
Outer Wall Exterior Coating | double sided 4 mm High galvanizing purification plate |
|
|
Heat and Sound Insulation | 50mm silicon rock board, A class a fire protection and insulation (80 kg/m3) |
Fire Resistance | According to DIN 4102, A2 Class Fire Resistant |
Outer Wall Inner Coating | double sided 4 mm High galvanizing purification plate |
3.6) Internal Wall System of Lida Folding Container House( Foldable Container House)
Inner Wall Thickness | 50mm silicon rock board, A class fire protection and insulation |
Inner Wall Exterior Coating | double sided 4 mm High galvanizing purification plate |
Heat and Sound Insulation | 50mm silicon rock board, A class a fire protection and insulation (80 kg/m3) |
Fire Resistance | According to DIN 4102, A2 Class Fire Resistant |
3.7) Doors of Lida Folding Container House( Foldable Container House)
OUTER DOORS
Dimensions | 890 x1960 mm |
Door | Galvanized sheet with honeycomb paper insulation |
double sided 4mm galvanized iron plate |
|
Door Frame | 2 mm thickness galvanized sheet (Electrostatic painted) |
Lock/Handle | Copper core long handle lock |
WC DOORS
Dimensions | 620 x 2000 mm |
Door | PVC folding toilet door/ Aluminum alloy glass door |
Door Frame | 2 mm thickness galvanized sheet (Electrostatic painted) |
Lock/Handle | Cylindrical lock / colored metal door handles |
3.8) Windows of Lida Folding Container House( Foldable Container House)
Window | 950 x 1200mm 50 series of aluminum alloy Casement window |
Transom Window | 400 x 600 cm Aluminum alloy sliding window |
3.9) Glass Data of Lida Folding Container House( Foldable Container House)
Window | 4+12+4 Tempered glass |
Transom Window | 4 mm thickness frosted glass |
3.10) Paint of Lida Folding Container House( Foldable Container House)
All our paints are water-based polyurethane topcoat, Chen Yang brand.
We welcome you to contact us for more information of
prefab house and look forward to working with you !
