LIDA INTEGRATED LABOR CAMP NORMALLY

INCLUDES THE FOLLOWING BUILDINGS AS FOLLOWING

Another benefit of steel structure buildings is their cost-effectiveness. Steel is a relatively inexpensive material compared to other building materials such as concrete and wood. Additionally, steel buildings can be constructed quickly, which can save time and money on construction costs. This makes steel structures an attractive option for developers looking to build high-quality buildings at a reasonable cost.

Type

With or without steel chassis

Type one: without steel chassis, build on concrete strip foundation
Type two: with steel chassis, the building will be put on concrete blocks

Storey

One storey or two storey or three storey are available

Frame system

Steel column

Q235 Steel, 100*100*2.5 square tube, alkyd painting, twice primer paint & twice finish paint

Steel roof truss

C100*40*15*2.0, welding and galvanized

Roof and wall purlin

C100*40*15*2.0, galvanized

Cross bracing

Q235 Steel, L40*3 angle steel, alkyd painting, twice primer paint & twice finish paint

Chemical bolt

M16, chemical bolt

Ordinary bolt

4.8S, galvanized

Steel chassis or 1st floor system

Main beam

HN250*125*5.5*8, Q235 Steel, alkyd painting, twice primer paint & twice finish paint

Secondary beam

C100*40*15*2.0 galvanized

Floor structure board

18/20mm plywood and fiber cement board

Flooring

PVC floor leather and ceramic tiles are available

Wall and Roof system

Wall panel

Sandwich panel: Rock wool, Glass wool, EPS, PU are available
Thickness: 50mm, 75mm, 100mm, 150mm, 200mm are available

Roof panel

Sandwich panel: Rock wool, Glass wool, EPS, PU are available
Thickness: 50mm, 75mm, 100mm, 150mm, 200mm are available

Ceiling system

Dry room

600*600*6mm gypsum board,with framework

Wet room

600*600*5mm calcium silicate board, with framework

Door and window system

Door

Fire resistant steel single/double door, emergency door with panic bar, aluminum glass door, MDF door are available

Window

PVC, Aluminum sliding window with single/double glazed glass, with mosquito screen, with louver are available

Electric and Plumbing system

Electric units

Electric wire, conduit, socket, switch, light, distribution box

Sanitary units

Shower, closestool, basin, water pipe
