container house environmental mobile tiny house

这里可以自定义设置
container house environmental mobile tiny house
B站不支持收货地址
B站不支持库存规格
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
Lida
Material:
Steel
Use:
Hotel, House, Kiosk,Booth, Office, Sentry Box,Guard House, Shop, Toilet, Villa, Warehouse, Workshop,Plant
container house mobile tiny house:
mobile tiny house
Supply Ability
Supply Ability:
80 Set/Sets per Month
  container house environmental  mobile tiny house




Dimensions and Weight

 20 ft

Inner length /external length :5.81m/6.06m

Inner width /external width: 2.188m/2.438m

Inner height/external height:2,410m/2.591m



Weight: 2000kg per uni

Steel framework



 Material: steel material Q234, thickness: 3.5mm,for top beam frame. Base beam frame and column.

 Surface working: epoxy painting,two bottom and two surface.

 Fittings: 8 standard container corner mould fittings PVC standard rainwater pipe

 Forklift openings: size 100*250mm, distance is 1200mm



Floor



External wainscot: Flat galvanized color steel sheet, 0.5mm thickness

 Floor structure: Girder made of 3.5mm steel. The purlin is C section steel. dimension 60x40x1.5mm.

 Warm proof Insulation layer: 75mm rock wool

 18mm  plywood

 1.5mm PVC floor leather for living rooms floor;



 Ceiling



Construction:

 Roof exterior layer: 1.2mm steel plate with epoxy painting

 Warm proof insulation filling: 75mm rockwool between C section purlins;

 Inner wainscot: 8mm OSB board with 12mm PVC decoration board.

 Roof water drain: 4 PVC rainwater pipes in the corner pillars, diameter 50mm



Walls



Panel width: 1150mm; panel total thickness: 75mm, five panels fit into the long side and two panels fit into the short side.

 Construction:

 Common room wall: 75mm rockwool 0.4/0.4mm Galvanized

 steel on both side , Desity of Rockwool: 120Kg/m3

 Galvanize window opening on the wall if needed.

Door



External door: Insulated with opening dimension 950*2100mm, furnished with lock

 with 3keys. Inner door: Insulated steel door.



Windows



 Window material: PVC window with fly screen. 5mm glass.



Electrical fittings option



Electrical wire, 2.5mm2 for lighting system, and 4mm2 for AC units.

 Main outlet and input industrial socket with 32A.

 3 pcs 16A five hole universal socket.

 2 pc double tube fluorescent lamp, 220V,50-60HZ

 1 pc Single Switch, Honyar brand, with junction box

 1 pc Electrical distribution box, box+breakers+earth leakage protective device



Optional Water system fittings



Water drain pipe, PPR pipe, dim 16-20mm, connection fittings are made of copper, life span over 10 years.

 Exhaust fan or air exchange hole, size 250mm*250mm made of steel or PVC

 Sanitary ware:

 Western Close tool: ceramic, with pipes and installation fittings

 Urinal: ceramic, with pipes and installation fittings

 Wash basin: ceramic, with post, faucet, pipes and installation fittings

 Shower head, Shower base, Water mixture


Technical Parameter:

Size: GP20, GP40 and HP40 of shipping container

Wind Resistance: Grade 12

Wall permitted loading: 0.6KN/ m2

Ceiling Permitted live loading: 0.5 KN/m2

Wall Coefficient of thermal conductivity: K=0.442W/mk

Ceiling Coefficient of thermal conductivity: K=0.55W/ m2K





Packaging & Shipping





Our Services



1. Professional design and engineering team: Full solution for site camp design. We could make the design for whole camp as per your requirement.



 2. Procurement and Manufacture for all material for prefabricated building. We have a professional procurement team to make sure all the materials are with good quality. And our factory operation under ISO standard, to make sure the fabrication works with high technology.







3. Site management & Installation supervision, We could send our engineers to help for the installation supervision, you just need to prepare a team which know normal construction works will be OK.





FAQ





Why Choose Container for Site Camp Solution? There are many advantages to modular camp construction for site camps including:







1) Good ability to assemble and disassemble for several times without damage. 2) Could be lifted, fixed and combined freely. 3) Heatproof and waterproof. 4) Cost saving and convenient transportation (Each 4 container house can loaded in one standard container) 5) Service life can reach up to 15 - 20 years 6) We can provide the service of installation, supervision and training by extra.





Company Information



Our Weifang Henglida Steel Structure Co.,Ltd.( Lida Group)  is one of the largest manufacturers of the prefabricated house, Flat Pack container house, steel villas, and steel structure warehouse in China. We have been doing well in this field for more than 20 years, and we have exported our products to more than 96 countries as well as our domestic market  with  ISO9001, CE and SGS approval.









Lida Group strives to become a green and efficient prefab house company. This product has the advantage of excellent sealability. What makes Lida Group unique in the prefab house industry is that we only produce the best and highest prefab house with a favored price. This product has the advantage of excellent sealability.
