Custom top steel buildings shipped to business for warehouse 1
Custom top steel buildings shipped to business for warehouse 1

Custom top steel buildings shipped to business for warehouse

Inquiry
Company Advantages
1. Lida Group is created in line with the principle of 'Quality, Design, and Functions'. This product is able to go through heavy rains or hurricanes
2. This product has revolutionized the transportation of goods and ultimately the international export market as turnaround time, theft, damage to goods and costs all went down. This product is characterized by its ventilation design
3. It's easy to operate for our top steel buildings . This product has the advantage of excellent sealability
4. top steel buildings has several advantages such as . This product has low demands for the subgrade
Overview
Quick Details
Warranty:
3 years
After-sale Service:
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement
Project Solution Capability:
graphic design, 3D model design, Cross Categories Consolidation
Application:
Warehouse, Workshop
Place of Origin:
Shandong, China
Brand Name:
LIDA
Model Number:
LDS
Main frame:
Q345B,H/I section beam
Certificate:
CE EN1090,BV,SGS,ISO9001
Insulation:
50mm,75mm,100mm
Wall and roof:
sandwich panel or corrugated sheet
Max clear span:
36m
Max Life Time:
more than 50 years
Keywords:
Light Steel Structure
Supply Ability
Supply Ability:
500 Ton/Tons per Month

easy installation modular steel buildings prefab structural residential steel building sandwich panel homes house



Custom top steel buildings shipped to business for warehouse 2

Custom top steel buildings shipped to business for warehouse 4

Product Description



I. Description:

Lida Light steel structure building is a new type of building structure system, The building structure system is formed by the main steel framework through linking up H section, C section, Z section or U section steel components. Maintenance system uses different kinds of panels as wall and roof together with other components such as windows and doors.
Lida light steel structure building is widely used in large factories, warehouses, workshops, bridges, stadiums and other buildings.

II. Characteristics:

1. Wide span: single span or multiple spans, the max span clear distance is 36m, without middle columns.
2. Low cost: unit price range from USD35 to USD70/square meter FOB according to customer’s request.
3. Fast construction and easy in installation
4. Long term service life: more than 50 years.
5. Other characteristics: environmental protection, stable structure, earthquake resistance, water proofing, and energy saving.

III. Main parts of the steel structure building:

   Light steel structural

   Main Steel Frame

H section steel

Q345 steel 8mm/10mm

Galvanized or Painting

Cross Support

Φ20, Steel Q235,

Galvanized

Belt Bar

Φ89*3, Steel Q235

Galvanized

Small Brace

Φ12,Steel Q235

Galvanized

Ordinary Bolt Galvanized Bolt

roof

Purlin

C160*60*2,Steel Q235,

 Galvanized

Out-roof Panel

Sandwich Panel or

corrugated steel sheet

FRP daylighting board

thickness 1.2mm

Accessories

Glass glue,

self-tapping screw etc.

Edge Cover

Made of color steel sheet

thickness 0.5mm

Gutter

Made of steel sheet

thickness 0.8mm

Rainspout

Φ110 PVC
wall

Purlin

C160*60*2.5,

Steel Q235, Galvanized

Wall

sandwich panel or

corrugated steel sheet

Accessories

Glass glue,

Self-tapping Screw etc.

Edge Cover

Made of color steel sheet

thickness 0.4mm

Axial fan Axial Fan
Door

sliding door or Rolling shutter door

Window PVC or Aluminium alloy
Crane With or without crane in 5 tons to 20 tons

Our excellent design team will design warehouse metal for you. If you give the following information, we will give you an satisfactory drawing:



1 Location (where will be built? ) _____country, area
2 Size: Length*width*height _____mm*_____mm*_____mm
3 wind load (max. Wind speed) _____kn/m2, _____km/h, _____m/s
4 snow load (max. Snow height) _____kn/m2, _____mm
5 anti-earthquake _____level
6 brickwall needed or not If yes, 1.2m high or 1.5m high
7 thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; If not, the metal steel sheets will be ok. The cost of the latter will be much lower than that of the former.
8 door quantity & size _____units, _____(width)mm*_____(height)mm
9 window quanity & size _____units, _____(width)mm*_____(height)mm
10 crane needed or not If yes, _____units, max. Lifting weight____tons; Max. Lifting height _____m



 Lots of customers have visited our factory and give us high appraise.

And you are warmly welcomed to vist our factory!

Project Show

Custom top steel buildings shipped to business for warehouse 6Custom top steel buildings shipped to business for warehouse 8Custom top steel buildings shipped to business for warehouse 10

Products show

Custom top steel buildings shipped to business for warehouse 12



Main Mareial

Custom top steel buildings shipped to business for warehouse 14

Stable steel frame



Custom top steel buildings shipped to business for warehouse 16

Show details

Custom top steel buildings shipped to business for warehouse 18





Company Information

  We Weifang Henglida Steel Structure Co.,Ltd.( Lida Group)  is one of the largest manufacturers of the prefabricated house, Flat Pack container house, steel villas, and steel structure warehouse in China. We have been doing well in this field for more than 20 years, and we have exported our products to more than 110 countries as well as our domestic market  with  ISO9001, CE ,BVand SGS approval.

          Custom top steel buildings shipped to business for warehouse 20

Contact us

Custom top steel buildings shipped to business for warehouse 22





For my construction projects, this product could be an ideal solution. It is able to match my scheduled architectural styles.- Said one of our customers. This product has been widely used in offices, meeting rooms, dormitories, shops, booths, etc. The product has greatly helped my building project stand out in the crowd. I love its eye-catching shapes and appearances. - Said one of our customers. This product has been widely used in offices, meeting rooms, dormitories, shops, booths, etc.

Company Features
1. Lida Group has been recognized as a professional and experienced top steel buildings manufacturer worldwide. We are supported by a sales and marketing team scaled for global markets. They work hard to deliver our products to the rest of the world through our wide sales network.
2. A professional team is a strong guarantee of good work and good service of Lida Group.
3. Lida Group is concentrated on the production on with new technologies. Lida Group always insists on providing better service to customers. Inquire online!
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
