Customized shipping modular home with fiber glass sandwich panel

这里可以自定义设置
Customized shipping modular home with fiber glass sandwich panel
B站不支持收货地址
B站不支持库存规格
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
Lida Group
Model Number:
LD-CH15
Material:
Container
Use:
Carport, Hotel, Kiosk,Booth, Office, Shop, Toilet, Warehouse
20 ft Inner /external width::
2.188m/2.438m
20 ft Inner /external length:
5.81m/6.06m
20 ft Inner /external height:
2,410m/2.591m
Wall permitted loading::
0.6KN/ m2
Ceiling Permitted live loading::
0.5 KN/m2
Wind Resistance::
Grade 12
Ceiling Coefficient:
K=0.55W/ m2K
Wall Coefficient of thermal conductivity:
K=0.442W/mk
Special requirements of customers:
customizable
Supply Ability
Supply Ability:
300 Set/Sets per Month



Product Description





Why Choose Container for Site Camp Solution?



There are many advantages to modular camp construction for site camps including:



(1).Good ability to assemble and disassemble for several times without damage.



(2).Could be lifted, fixed and combined freely.



(3).Heatproof and waterproof.



(4).Cost saving and convenient transportation (Each 4 container house can loaded in one standard container)



(5).Service life can reach up to 15 - 20 years



(6).We can provide the service of installation, supervision and training by extra.











container house Material list: Light steel structure, steel material Q235

Surface working: sand blasting, epoxy basic painting 55μm, final vinyl acrylic painting 55μm thick

Fittings: 8 standard container corner mould fittings PVC standard rainwater pipe





Wall and roof panel:

galvanized Color steel sheet 0.3~0.5mm on both sides,
inside thickness 50~200mm EPS,
Rock wool, Fiber glass, PU sandwich panel

Packaging & Shipping



Remark:

1, One 40’ft HQ container can load 5 units 20ft standard flat-pack container.

2, 4 sets standard flat pack containers can be shipped to your pointed port as the shipping container.

3, If you only need structure, we can loaded into shipping container or shipped as directly.

4, If the length of 40’ft container narrowed( narrow the length to 11.8 meter), we can load 5 units steel frame into one 40ft HQ shipping container.

5, If the length of 20’ft container narrowed(narrow the length to 5.8 meter), we can load 10 units steel frame into one 40ft HQ shipping container.

 Our successful container house project:



Our WeifangHenglida Steel Structure Co.,Ltd.( Lida Group) is one of the largest manufacturers of the prefabricated house, Flat Pack container house, steel villas, and steel structure warehouse in China. We have been doing well in this field for more than 21 years, and we have exported our products to more than 90 countries as well as our domestic market with ISO9001, CE and SGS approval.Lida Group is a supplier of the series products for the country’s key projects, such as the Olympic Sailing Centerbay bridge of Jiaozhou Gulf, Qingdao cross sea tunnel, etc.



Our factory:





Lida Group have become the preferred brand for many costumers with its excellent quality, perfect service and competitive price. This product is highly adaptable to dynamic loads. Lida Group can guarantee punctual delivery with high efficiency. This product is highly adaptable to dynamic loads.
