Foldable Container House Easy To Carry And Shipping

INTRODUCTION OF CONTAINER HOUSE.

Container house is designed and developed according to the standard size of shipping container. It is of heatproof and waterproof. It is widely used as office, meeting room, dormitory, shop, booth, toilet, storage, kitchen, shower room and so on.

Lida container houses include flat pack container house, foldable container house, expandable container house, welding container house(customized container house)and modified shipping container house(converted shipping container house).

Lida Folding Container House

Lida folding container house (foldable container house) is designed and developed according to the standard size of shipping container. Transportation is designed in accordance with a standard ISO shipping container. The corner casting structure enables lifting capability utilizing a crane in the same manner as a standard ISO shipping container. It is of heatproof and waterproof. It is widely used as Site office, Disaster relief materials reserve, emergency shelter house, site living room, meeting room, dormitory, shop, toilet, storage, kitchen, shower room and so on. Light material without overload, easy to pack and transport.

The house can be assembled and disassembled more than 10 times, and the service life is more than 15 years.

Characteristics of Lida Folding Container House

( Foldable Container House)

Good ability to assemble and disassemble for several times without damage.

Could be lifted, fixed and combined freely.

Heatproof and waterproof.

Cost saving and convenient transportation (10 container house can be loaded in one 40HQ shipping container)

Service life 15-20 years

We can provide the service of installation, supervision and training by extra.

Technical Parameter of Lida Folding Container House( Foldable Container House)

(1).Size: GP20, GP40 and HQ40
(2).Wind Resistance: Grade 12
(3).Wall permitted loading: 0.6KN/ m2
(4).Ceiling Permitted live loading: 0.5 KN/m2
(5).Wall Coefficient of thermal conductivity: K=0.442W/mk
(6).Ceiling Coefficient of thermal conductivity: K=0.55W/ m2K

Technical Parameter of Lida Folding Container House

3.3) Floor System of Lida Folding Container House( Foldable Container House)

Floor layer	18mm cement silicon calcium board
Floor Covering	PVC floor leather, the wear-resistant layer is 0.07mm.
Load Capacity	A1 class fireproof, 18mm thick density 1.75-1.95g/cm3; high strength floor.
Cushioning cushion	Industrial felt, cushioning, sound insulation, sealing, shockproof.
Sealant sea	lHigh density polyurethane foam is used to completely seal waterproof, moisture-proof and noise reduction.

3.4) Roof System of Lida Folding Container House( Foldable Container House)

TYPE	SPECIFICATION MODEL
Roof material	Choose 6 2870mm950mm50mm* double sided 4mmEPS board, cleaning plate, rivet.
Support force	The 30mm30mm3mm angle iron is selected to directly weld the top frame and the 100mm50mm2.8mm*3000mm galvanized square tube is used as the supporting beam.
Top waterproof	7mm1000mm6000mm galvanized coiling machine is used for mechanical interlocking. The rivet and 995 structural adhesive are all sealed around.

3.5) Exterior Wall System of Lida Folding Container House( Foldable Container House)

Outer Wall Thickness	50mm silicon rock board, Aclass a fire protection and
Outer Wall Exterior Coating	double sided 4mmHigh galvanizing purification plate

Heat and Sound Insulation	50mm silicon rockboard, Aclass a fire protection and insulation (80kg/m3)
Fire Resistance	According to DIN 4102, A2Class Fire Resistant
Outer Wall Inner Coating	double sided 4mmHigh galvanizing purification plate

3.6) Internal Wall System of Lida Folding Container House( Foldable Container House)

Inner Wall Thickness	50mm silicon rock board, Aclass fire protection and insulation
Inner Wall Exterior Coating	double sided 4mmHigh galvanizing purification plate
Heat and Sound Insulation	50mm silicon rock board, Aclass a fire protection and insulation (80kg/m3)
Fire Resistance	According to DIN 4102, A2Class Fire Resistant

3.7) Doors of Lida Folding Container House( Foldable Container House)

OUTER DOORS

Dimensions	890 x1960 mm
Door	Galvanized sheet with honeycomb paper insulation
double sided 4mm galvanized iron plate
Door Frame	2mm thickness galvanized sheet (Electrostatic painted)
Lock/Handle	Copper core long handle lock

WC DOORS

Dimensions	620 x 2000 mm
Door	PVC folding toilet door/Aluminum alloy glassdoor
Door Frame	2mm thickness galvanized sheet (Electrostatic painted)
Lock/Handle	Cylindrical lock / colored metal door handles

3.8) Windows of Lida Folding Container House( Foldable Container House)

Window	950x 1200mm 50 series of aluminum alloy Casement window
Transom Window	400x 600cm Aluminum alloy slidingwindow

3.9) Glass Data of Lida Folding Container House( Foldable Container House)

Window	4+12+4 Tempered glass
Transom Window	4 mm thickness frosted glass

3.10) Paint of Lida Folding Container House( Foldable Container House)
All our paints are water-based polyurethane topcoat, Chen Yang brand.

Characteristics of Lida Folding Container House( Foldable Container House)

1) Good ability to assemble and disassemble for several times without damage.
2) Could be lifted, fixed and combined freely.
3) Heatproof and waterproof.
4) Cost saving and convenient transportation (10 container house can be loaded in one 40HQ shipping container)
5) Service life 15-20 years
6) We can provide the service of installation, supervision and training by extra.

3.1) Standard Dimension of of Lida Folding Container House( Foldable Container House)

STANDART DIMENSIONS
TYPE	LENGHT	WIDTH	OUTER HEIGHT	INNER HEIGHT	~WEIGHT
STANDARD HOUSE	6000mm	3000mm	2780mm	2550mm	±2000kg
CONTAINER TEANSPORT SIZE	5800mm	2400mm	2500mm	2270mm	±1700kg

3.2) Steel Structure of Lida Folding Container House( Foldable Container House)

Main body structure

Fully automatic seamless welding equipment, waterproof frame design, Q235 high zinc coating, thickness of 2mm, full welding of the frame, solid structure, fast installation.

Base frame

Adopting step waterproof design, 3mm galvanized steel is used, one time extrusion forming, and high strength supporting structure design.

3.11) Electric System of Lida Folding Container House( Foldable Container House)

TYPE	MODEL SPECIFICATION		QUANTITY	REMARKS
Voltage design	220v/50Hz			National standard
Electric Wire and Cable	Main Wire	4m²	3m	National standard
	lighting Wire	4m²	24m	National standard
	air conditioning Wire	4m²	3m	National standard
	Socket Wire	4m²	16m	National standard
	Lightning protection Ground wire	1.5m²	36m	National standard
Socket	alphabet fast plug	32A	1 sets	European standard
	Air conditioning socket	16A	1 sets	Zhengtai
	five hole socket	10A	1 sets	Zhengtai
	switch socket	10A	1 sets	Zhengtai
Leakage protector	Leakage protector	32A	1 sets	Zhengtai
Safety box	Pc Electrical distribution box		1 sets	Zhengtai
Lighting	LED ceiling lamp	18w	2 sets	National standard
Lighting	LED safety lamp	15w	1 sets	National standard

3.12) Sanitary of Lida Folding Container House( Foldable Container House)

Pipes (Clean Water)	PPRC Pipe (National standard) External
Pipes (Waste Water)	PVC Pipe (National standard) External

Sanitary Ware

Washbasin	Ceramics
Washbasins Tap	Taps are wall mounted
Shower Tray	Special type Acrylics
Shower Faucet	Mix Bath Faucet
Toilet Wash Tap	Taps are wall mounted

We welcome you to contact us for more information of

prefab house and look forward to working with you !
