Specifications
Light steel structure simple villa projects is easy to assemble and disassemble for several times and cost saving and transport.
Light steel structure simple villa projects:
1) Light steel structure modular house.
2) Wall panels and roof panels are color steel sandwich panels
3) Doors, windows and interior partitions fixed flexibly
4) Easy to assemle and disassemble for several times without damage
5) Cost saving and transportation convenient
6) Anti-rust and normally more than 10 years using life
Please contact us for further more information.
Main Material (for standard house):
No. | Part name | Material name | Description |
|
1 | ground channel | C shape steel | C80x40x15x2.0 |
|
2 | column | Double C shape steel | 2C80x40x15x2.0 welded |
|
3 | Beam for second floor | Steel frame | 2C80x40x15x2.0,L40x4 welded |
|
4 | Sub-beam for second floor | C shape steel | C80x40x15x2.0 |
|
5 | Purlin for roof | Corner steel | L40x4 |
|
6 | Bracing for roof | Corner steel | L40x4 |
|
7 | Bracing for aisle and rain shelter | C shape steel | C80x40x15x2.0 welded |
|
8 | Bracing between the columns | Round steel,bolt | φ8 |
|
9 | Step board | Steel board | t=3.0mm |
|
10 | stair | Steel stairs |
|
|
11 | Wall panel | V950 EPS sandwich panel | 50mm thickness,steel plate:0.3mm |
|
12 | Partition panel | V950 EPS sandwich panel | 50mm thickness, steel plate:0.3mm |
|
| ||||
13 | Roof panel | V950 EPS sandwich panel | 50mm thickness, steel plate: 0.3mm |
|
14 | Floor for second storey | plywood | 16mm thickness |
|
15 | Rain shelter | One layer color steel plate | 0.45mm thickness |
|
16 | windows | PVC sliding windows | 0.93mx1.715m |
|
17 | door | Sandwich panel door | 0.85mx2.1m |
|
18 | Entensive and commonbolt |
| Different dimension |
|
|
Technical Parameter of standard prefabricated house:
Wind resistance: Grade 11(wind speed≤111.5km/h)
Earthquake resistance: Grade 7
Live load capacity of roofing: 0.5kn/m2
External and internal wall heat transmission coefficient: 0.35Kcal/m2hc
Second Floor Load Capacity: 150 kg/m2
Live load of corridor is 2.0kn/ m2
We can design and produce the house according to customer’s request.
1.Our advantages:
Lida Group has leading R & D capabilities and technology advantages, and its products such as steel structure series, modular house series, and light steel sandwich panels series are widely used in industry, traffic, city construction, commercial and other temporary accommodation. With the advanced technology, full products range, excellent sales and service teams, Lida’s products are sold throughout the home and abroad markets. Lida Group is a supplier of the series products for the country’s key projects, such as the Olympic Sailing Center, bay bridge of Jiaozhou Gulf, Qingdao cross sea tunnel, etc. Lida Group has the right of import and export, and its products have been exported to over 80 countires, such as,the UAE, Saudi Arabia, Oman, Angola, Equatorial Guinea,Libya,France, Poland, Romania, Russia, Australia, the Philippines, Indonesia ...etc.
2. Our company:
Our Weifang Henglida Steel Structure Co.,Ltd.( Lida Group) is one of the largest manufacturers of the prefabricated house, Flat Pack container house, steel villas, and steel structure warehouse in China. We have been doing well in this field for more than 21 years, and we have exported our products to more than 90 countries as well as our domestic market with ISO9001, CE and SGS approval.
