High-quality manufactured home designs Suppliers for Movable Shop

No.

Item

Specification & Remark


Summary of the prefab home

Type 1

There are two type of prefab house, one of the main difference is that Type 2 cannot see the steel frame from the out/inner surface while Type 1 can be seen from the out surface.

Type 1 has its own standard size, please refer to the following details.

Type 2 can be manufactured according to the customers’ specific requirements.

Type 2

1

Length

Length=NK.(K=1800mm, N is a whole number equal to or any bigger than two)

Width

5560mm,6230mm,7360mm,8250mm, adjust accrodlingly.

Height

Width=3P,6P,or 9P(P=950mm, 3Pis one storey, 6Pis two storey and 9Pis three storey.)

Roof slope

Slope is 1:10 ~ 1:5

Floors

Less than 3 floors

2

Steel frame prefab home

Steel columns/pillars

Square steel tube(Q235) 50x50x2.0mm

Steel Truss

3

Roof  and  wall panel

50mm thickness Rock Wool  insulation corrugated panel,

(Alternative EPS or fiber glass)

0.4mm steel sheet,120Kg/m3 rock wool density,

 Heat Insulated coefficient is 0.041w/m.k.

 Heat transfer coefficient is 0.58w/•k.

4

Edge cover

0.5mm thickness color steel plate

5

PVC window

white color, glazed with glass in a thickness of 4mm,

two bay fixed and two bay sliding, with fly screen.

(Alternative plastic steel frame, glass window)

6

Prefab house ceiling

6mm thickness gypsum board or PVC board

7

Door for prefab home

White color sandwich panel window,

furnished with a cylinder lock with keys

The door can be alternated by the clients’ requirements.

8

Floor

1.5mm thickness PVC floor leather

18mm plywood

9

Electric cable,

PVC wire Channel

10

Lights, Switches, Socket, Power distribution cabinet

11

Washing/ shower room

It could include the toilet, washing basin and shower

12

Nails, expansion bolts, glue and so on

all fittings

13

Technical parameter

Live load capacity of roofing

0.5kn/m2

 prefab house materials

Second floor load capacity

150kg/m2

Bearing load

30kg/m2
