Overview

Quick Details

Place of Origin:: Shandong, China

Brand Name:: Lida Group

Model Number:: LD-CH51

Use:: Hotel, House, Office, Toilet, Villa, Warehouse, campsite

20 ft Inner length /external length:: 5.81m/6.06m

Inner width /external width::: 2.188m/2.438m

Inner height/external height:: :2,410m/2.591m

Wind Resistance of container house:: Grade 12

Wall permitted loading::: 0.6KN/ m2

Ceiling Permitted live loading::: 0.5 KN/m2

Wall Coefficient of thermal conductivity:: : K=0.442W/mk

Ceiling Coefficient:: K=0.55W/ m2K

Supply Ability

Supply Ability:: 300 Set/Sets per Month

Company Information

Our WeifangHenglida Steel Structure Co.,Ltd.( Lida Group) is one of the largest manufacturers of the prefabricated house, Flat Pack container house, steel villas, and steel structure warehouse in China. We have been doing well in this field for more than 21 years, and we have exported our products to more than 90 countries as well as our domestic market with ISO9001, CE and SGS approval.Lida Group is a supplier of the series products for the country’s key projects, such as the Olympic Sailing Center, bay bridge of Jiaozhou Gulf, Qingdao cross sea tunnel, etc.

Our factory in Weifang:

Our big family

Product Description

Our successful container house project:

Why Choose modular container house for Campsite project?

There are many advantages:

(1).Good ability to assemble and disassemble for several times without damage.

(2).Could be lifted, fixed and combined freely.

(3).Heatproof and waterproof.

(4).Cost saving and convenient transportation (Each 4 container house can loaded in one standard container)

(5).Service life can reach up to 15 - 20 years

(6).We can provide the service of installation, supervision and training by extra.

Materials of flat pack modular container house:

Steel frame of container house
(1). Material: steel material Q345, thickness: 3.5mm,for top beam frame.
(2).Surface working: epoxy painting,two bottom and two surface.
(3).Fittings: 8 standard container corner mould fittings PVC standard rainwater pipe
(4).Forklift openings: size 100*250mm, distance is 1200mm

Steel frame of container house

(1). Material: steel material Q345, thickness: 3.5mm,for top beam frame.

(2).Surface working: epoxy painting,two bottom and two surface.

(3).Fittings: 8 standard container corner mould fittings PVC standard rainwater pipe

(4).Forklift openings: size 100*250mm, distance is 1200mm

Floor in container hosue
(1).External wainscot: Flat galvanized color steel sheet, 0.5mm thickness
(2).Floor structure: Girder made of 3.5mm steel. The purlin is C section steel. dimension 60x40x1.5mm.
(3).Warm proof Insulation layer
(4)18mm bamboo plywood
(5)2.0mm PVC floor leather for living rooms floor;

Floor in container hosue

(1).External wainscot: Flat galvanized color steel sheet, 0.5mm thickness

(2).Floor structure: Girder made of 3.5mm steel. The purlin is C section steel. dimension 60x40x1.5mm.

(3).Warm proof Insulation layer

(4)18mm bamboo plywood

(5)2.0mm PVC floor leather for living rooms floor;

Ceiling of container house
(1).Container house Roof exterior layer: 1.2mm steel plate with epoxy painting
(2).Warm proof insulation filling: 50~200mm rockwool/fiber glass sandwich panel/EPS/PU between C section purlins;
(3).Inner wainscot: 8mm OSB board with 12mm PVC decoration board.
(4).Roof water drain: 4 PVC rainwater pipes in the corner pillars, diameter 50mm

Ceiling of container house

(1).Container house Roof exterior layer: 1.2mm steel plate with epoxy painting

(2).Warm proof insulation filling: 50~200mm rockwool/fiber glass sandwich panel/EPS/PU between C section purlins;

(3).Inner wainscot: 8mm OSB board with 12mm PVC decoration board.

(4).Roof water drain: 4 PVC rainwater pipes in the corner pillars, diameter 50mm

Walls
(1).Panel width: 1150mm; panel total thickness: 75mm, five panels fit into the long side and two panels fit into the short side.
(2).Common room wall: 50~200mm insulation 0.3~0.5mm Galvanized color steel sheet. Steel on both side .
(3).Galvanize window opening on the wall if needed.

Walls

(1).Panel width: 1150mm; panel total thickness: 75mm, five panels fit into the long side and two panels fit into the short side.

(2).Common room wall: 50~200mm insulation 0.3~0.5mm Galvanized color steel sheet. Steel on both side .

(3).Galvanize window opening on the wall if needed.

Door&window in container homes
(1).External door: Insulated with opening dimension 950*2100mm, furnished with lock with 3keys.
(2).Inner door: Insulated steel door.
window for container house
Window material: PVC window with fly screen. Double glass, 4mm glass.

Door&window in container homes

(1).External door: Insulated with opening dimension 950*2100mm, furnished with lock
with 3keys.

(2).Inner door: Insulated steel door.

window for container house

Window material: PVC window with fly screen. Double glass, 4mm glass.

Electrical fittings option
Electrical wire, 2.5mm2 for lighting system, and 4mm2 for AC units.
Main outlet and input industrial socket with 32A.
3 pcs 16A five hole universal socket.
2 pc double tube fluorescent lamp, 220V,50-60HZ
1 pc Single Switch, Honyar brand, with junction box
1 pc Electrical distribution box, box+breakers+earth leakage protective device

Electrical fittings option

Electrical wire, 2.5mm2 for lighting system, and 4mm2 for AC units.

Main outlet and input industrial socket with 32A.

3 pcs 16A five hole universal socket.

2 pc double tube fluorescent lamp, 220V,50-60HZ

1 pc Single Switch, Honyar brand, with junction box

1 pc Electrical distribution box, box+breakers+earth leakage protective device

Our package: 4 in 1 container

FAQ

Packaging & Shipping

Our Services

One can benefit from the portability of this product, and the ability to create an extremely environmentally-efficient, self-sufficient living space. This product is distinguished by its sound and heat insulation. This product brings a unique style. It has such a distinctive look that it’s hard to capture this in one word, though people have tried: industrial, rugged, modern. This product is distinguished by its sound and heat insulation.
