Lida Group Best cheap shipping container house Suppliers used as office, meeting room, dormitory, shop

Lida Group Best cheap shipping container house Suppliers used as office, meeting room, dormitory, shop

Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
Product Information of Lida Group Best cheap shipping container house Suppliers used as office, meeting room, dormitory, shop
Company Advantages
1. Lida Group has to go through the life cycle assessment regarding its whole service life. The assessment includes its properties of chemical, physical, energy impacts. This product features level A fire protection grade
2. Without mature sales network, it could be very difficult for Lida Group to be so popular. This product can be patined with different colors
3. cheap shipping container house has a stable external structure with good carrying capacity and impact resistance. Moreover, it can meet the basic needs of customers based on complete internal facilities.
4. cheap shipping container house , made from excellent materials, has strong weather resistance to fully adapt to the all-weather environment. Besides, it has functions of heat insulation, heat preservation, sound insulation, and moisture proofness.
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
Lida Group
Model Number:
LD-C-01
Material:
Steel
Product name:
Prefab Warehouse
Door:
Steel Door
Window:
Steel Window
Roof:
Sandwich Panel. Single Steel Sheet
Main frame:
Steel Truss
Wall:
50mm/75mm Sandwich Panel
Standard:
ISO standard 20ft, 40ft are available
Type:
flat pack container and shipping container
Certificate:
ISO9001/SGS/CE/BV
Supply Ability
Supply Ability:
800 Set/Sets per Month
Specification1) 20ft: 6055*2435*2896mm
2) 40ft: 12192*2435*2896mm
3) Roof Type: Flat roof with organized internal water draining design
4) Storey: ≤3
Design parameter1) Life span: up to 20years
2) Floor Live load: 2.0KN/m2
3) Roof Live load: 0.5KN/m2
4) Wind load: 0.6KN/m2
5) Earthquake-resistance: Grade 8, Fire-proof: Grade 4
Wall panel1) Thickness: 75mm fiber glass sandwich panel, effective width: 1150mm
2) Exterior steel sheet (standard configuration): Corrugated 0.4mm       Aluminum-zinc color steel sheet, PE finishing coat, Color: white, Aluminum-zinc thickness≥40g/m2
3) Insulation layer (standard configuration): 75mm Fiber glass, density≥50kg/m3, Fire-proof standard: grade A non-flambable
4) Interior steel sheet(standard configuration): Flat 0.4mm Aluminum-zinc color steel sheet, PE finishing coat, Color: white, Aluminum-Zinc thickness≥40g/m2
Roof system1) Steel frame & accessories: Main roof frame: cold formed steel, thickness=2.5mm, galvanized. with 4pcs galvanized lifting corners. Roof purlin: C80*40*15*2.0, galvanized. Q235B steel
2) Roof panel: 0.4 or 0.5mm thickness Aluminum-zinc color steel sheet, PE finishing coat. Color: white, Aluminum thickness≥70g/m2, 360° full connection
3) Insulation: 100mm thickness Fiber glass with aluminum foil, Density=14kg/m3, Grade A fire-proof, nonflammable.
4) Ceiling board: V-170 type, 0.5mm Aluminum-zinc color steel sheet, PE finishing coat. Color: white, Aluminum-zinc thickness≥40g/m2.
5) Industrial socket: Fixed in explosion-proof box at the top beam of the short side, with 1 main power plug for power connection between containers
Corner pillar1) Cold rolled steel: 4pcs pillar with same dimension, thickness=3mm, steel grade Q235B.
2) Corner pillar and main frame are joined by hexagon socket head bolt, strength: grade 8.8. Filled with Fiberglass insulation
Floor System1) Steel structure & accessories: Main floor frame: cold formed steel, thickness 3.5mm, galvanization; Floor purlin:C120*40*15*2.0, galvanized. Q235B steel. Standard container is Without forklift hole, it can be added according to customer's requirement.
2) Insulation (optional): 100mm thickness Fiber glass with aluminum foil, Density=14kg/m3. Flammability:grade A, nonflammable.
3) Bottom covering (optional): 0.25mm color steel sheet, Zinc thickness≥70g/m2.
4) Floor board: 18mm thickness fiber cement board, Fire-proof:grade B1. Density≥1.3g/cm3
5) Interior Flooring: 1.5mm thickness PVC leather, Blue marble color
Door & Window1) Insulated light steel door: Entrance door is W850*H2030mm, Toilet door is W700*H2030mm.
2) PVC sliding window, double glass 5mm thickness, with mosquito screen and security bar. Standard window: W800*H1100mm(for 2.4meter's container), W1130*H1100mm(for 3 meter's container), Toilet window: W800*H500mm
Electric system1) Rated power: 5.0 KW, suggestion external power source ≤3 in series.
2) Technical parameters: CEE industrial plug, socket voltage 220V- 250V, 2P32A,  Fixed in explosion-proof box at the top beam of the short side, the electric cable in the roof is protected by PVC pipe with CE certification; Using IP44 standard power distribution box.
3) Electrical data: main power cable is 6 mm2, AC cable is 4 mm2, socket cable is 2.5 mm2, lighting & switch cable is 1.5 mm2. Five sockets, 1pc AC socket of 3holes 16A, 4pcs socket of 5holes 10A. 1pc single connection switch, 2pcs double tube LED light, 2*15W.
Painting1) Primer painting: epoxy primer, Zinc color, thickness: 20 - 40 μm.
2) Finishing paint:  Polyurethane finishing coat, white color, thickness: 40-50 μm. Total paint film thickness≥80μm. Galvanized components, galvanized layer thickness≥10μm (≥80g/m2)



Lida Group Best cheap shipping container house Suppliers used as office, meeting room, dormitory, shop-1Lida Group Best cheap shipping container house Suppliers used as office, meeting room, dormitory, shop-3Lida Group Best cheap shipping container house Suppliers used as office, meeting room, dormitory, shop-5Lida Group Best cheap shipping container house Suppliers used as office, meeting room, dormitory, shop-7



FAQ




Q: Are you factory or trading company?

A: Our Lida Group have main factory named Weifang Henglida Steel structure Co., Ltd., which is in Weifang city. Qingdao Lida construction Facility Co., Ltd. is in Qingdao city. Shouguang Lida Prefab House Factory is in Shouguang city, all of them are in Shandong province.



Q: How about your production capacity?

A: Pre engineered steel structure building (warehouse/workshop/hangar/shed/high rise apartment): 50000 sqm monthly. Prefabricated house (portacabin/labor camp/site office): 100000 sqm monthly. Prefab affordable house (low cost family/residential/refugee): 4200 units monthly. Container house: 800 units monthly. Light steel villa: 10000 sqm monthly.



Q: How about your quality control?

A: We have got certificate ISO9001:2015, certificate CE EN 1090. Products processing through cutting, bending, welding, shot blasting, ultrasonic testing, packing, storing, loading to ensure no quality defects.



Q: Is third party inspection available?

A: SGS, BV, TUV, etc. are available, it is according to client requirement.



Q: How about your delivery time?

A: Generally within 30 days, it is according to order quantity, partial shipment is allowed for big order.



Q: What about the installation?

A: We'll provide the detailed installation drawing, supervisors guiding installation is available. We can do turnkey job for some kind of projects.



Q: How to ensure the product you supply is what we want exactly?

A: Before placing order, our sales and engineers team will provide you the suitable solution according to your requirements. Proposal drawing, Shop drawing, 3D drawing, Materials photos, Finished projects photos are available, which will help you understand the solution we provided deeply.

With the help of this product, time, money, and labor are significantly saved and reduced. This product can greatly reduce the production cost of the manufacturer. This product is characterized by its ventilation design. The product is easily installed and comes with a complete detailed operation guide including user instructions, maintenance, and installation procedures. This product is characterized by its ventilation design.

Company Features
1. With advanced technology applied in cheap shipping container house , we take the lead in this industry.
2. Lida Group's mission is to offer the best lorry containers for sale for customers. Inquire online!
