Lida Group how to build a container home shipped to business used as booth, toilet, storage room

Lida Group how to build a container home shipped to business used as booth, toilet, storage room

Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
Product Information of Lida Group how to build a container home shipped to business used as booth, toilet, storage room
Company Advantages
1. Designed by professional engineers, how to build a container home is moderate in weight and is very convenient to move and transport. It can also be disassembled and assembled at will.
2. The product can be designed to help the building projects stand out, creating eye-catching shapes without compromising the infrastructure and appearances. Its appearance makes it compatible with the surrounding area
3. how to build a container home is made from safe, non-toxic and eco-friendly materials. It has good waterproof capability, fireproof property, heat insulation, heat preservation, and sound insulation. It can be reused to meet the requirements of energy-saving buildings.
4. Made from superior materials, how to build a container home is excellent in intensity and stability and is effective in resistance to wind, earthquake, high temperature, corrosion, and aging. Moreover, it has a high safety factor and long service life.
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
LIDA
Model Number:
Use:
Hotel, House, Office, Villa
Key words:
Qatar container house portacabins labor camp
Main frame:
3.5mm cold form Steel
Wall and roof:
75mm Galvanized Color Steel
Floor:
18mm Plywood + PVC floor Leather
Supply Ability
Supply Ability:
300 Unit/Units per Month
20ft cheap price flat pack container building a
Company Information
Our Weifang Henglida Steel Structure Co.,Ltd.( Lida Group) is one of the largest manufacturers of the prefabricated house, Flat Pack modulr 20ft cheap price flat pack container building a, LGS steel villas, and steel structure warehouse in China. We have been doing well in this field for more than 21 years, and we have exported our products to more than 90 countries as well as our domestic market with ISO9001, CE and SGS approval.Lida Group is a supplier of the series products for





 Lida Group how to build a container home shipped to business used as booth, toilet, storage room-1

 Lida Group how to build a container home shipped to business used as booth, toilet, storage room-3



Our big family:



Lida Group how to build a container home shipped to business used as booth, toilet, storage room-5





Product Description









 General technical description for Prefabricated Modular Container House

 Technical Parameter:

Size: GP20, GP40 and HP40
Wind Resistance: Grade 12
Wall permitted loading: 0.6KN/ m2
Ceiling Permitted live loading: 0.5 KN/m2
Wall Coefficient of thermal conductivity: K=0.442W/mk
Ceiling Coefficient of thermal conductivity: K=0.55W/ m2K
You are so welcome to send us inquiries!



Dimensions and Weight

Inner length /external length :5.81m/6.06m



Inner width /external width: 2.188m/2.438m



Inner height/external height:2,410m/2.591m



Weight: 2000kg per unit

Steel framework



 Material: steel material Q234, thickness: 3.5mm,for top beam frame. Base beam frame and column.



Surface working: epoxy painting,two bottom and two surface.



Fittings: 8 standard container corner mould fittings PVC standard rainwater pipe



Forklift openings: size 100*250mm, distance is 1200mm



Floor

External wainscot: Flat galvanized color steel sheet, 0.5mm thickness



Floor structure: Girder made of 3.5mm steel. The purlin is C section steel. dimension 60x40x1.5mm.



Warm proof Insulation layer: 75mm rock wool



18mm  plywood



1.5mm PVC floor leather for living rooms floor;





 Ceiling

Construction:



Roof exterior layer: 1.2mm steel plate with epoxy painting



Warm proof insulation filling: 75mm rockwool between C section purlins;



Inner wainscot: 8mm OSB board with 12mm PVC decoration board.



Roof water drain: 4 PVC rainwater pipes in the corner pillars, diameter 50mm



Walls

Panel width: 1150mm; panel total thickness: 75mm, five panels fit into the long side and two panels fit into the short side.



Construction:



Common room wall: 75mm rockwool 0.4/0.4mm Galvanized



steel on both side , Desity of Rockwool: 120Kg/m3

Galvanize window opening on the wall if needed.

Door





External door: Insulated with opening dimension 950*2100mm, furnished with lock



with 3keys. Inner door: Insulated steel door.

Windows

Window material: PVC window with fly screen. 5mm glass.





Electrical fittings option

Electrical wire, 2.5mm2 for lighting system, and 4mm2 for AC units.



Main outlet and input industrial socket with 32A.



3 pcs 16A five hole universal socket.



2 pc double tube fluorescent lamp, 220V,50-60HZ



1 pc Single Switch, Honyar brand, with junction box



1 pc Electrical distribution box, box+breakers+earth leakage protective device



Optional Water system fittings

Water drain pipe, PPR pipe, dim 16-20mm, connection fittings are made of copper, life span over 10 years.



Exhaust fan or air exchange hole, size 250mm*250mm made of steel or PVC





Sanitary ware:



Western Close tool: ceramic, with pipes and installation fittings



Urinal: ceramic, with pipes and installation fittings



Wash basin: ceramic, with post, faucet, pipes and installation fittings



Shower head, Shower base, Water mixture





Our Services

 1. Professional design and engineering team: Full solution for site camp design. We could make the design for whole camp as per your requirement.



 2. Procurement and Manufacture for all material for prefabricated building. We have a professional procurement team to make sure all the materials are with good quality. And our factory operation under ISO standard, to make sure the fabrication works with high technology.



3. Site management & Installation supervision, We could send our engineers to help for the installation supervision, you just need to prepare a team which know normal construction works will be OK.


FAQ

Why Choose Container for Site Camp Solution? There are many advantages to modular camp construction for site camps including:

1) Good ability to assemble and disassemble for several times without damage.
2) Could be lifted, fixed and combined freely.
3) Heatproof and waterproof.
4) Cost saving and convenient transportation (Each 4 modulr 20ft cheap price flat pack container building a can loaded in one standard container)
5) Service life can reach up to 15 - 20 years
6) We can provide the service of installation, supervision and training by extra.


Company Information



Our Weifang Henglida Steel Structure Co.,Ltd.( Lida Group)  is one of the largest manufacturers of the prefabricated house, Flat Pack modulr 20ft cheap price flat pack container building a, steel villas, and steel structure warehouse in China. We have been doing well in this field for more than 20 years, and we have exported our products to more than 96 countries as well as our domestic market  with  ISO9001, CE and SGS approval.



We would like to give fully support for your further inquiry!

Best regards
Steven Chen
---------------------------------------------------------
Weifang Henglida Steel Structure Co., Ltd.
Add: Room1102, Unit B, Zhonghui Commercial Building,Qingdao,266000,China
Tel: 0086-532-88966982    Fax: 0086-532-88965571
Moble: KSA: 00966-548943324 China: 0086-13869829462

Qatar modulr 20ft cheap price flat pack container building a portacabins labor camp



 Lida Group how to build a container home shipped to business used as booth, toilet, storage room-7

The whole manufacture process for prefab house is finished in Lida Group, so we can fully guarantee quality and technology. This product has been designed to last for decades. Lida Group has become more prominent and has gradually gained more market share in prefab house field. This product has been designed to last for decades.

Company Features
1. With salient capability in technology, Lida Group is superior than other companies in output and quality of how to build a container home .
2. Our mission is to provide innovative products and services at the highest level. We aim to surpass customer expectations of quality, delivery, and productivity.
