Material List For One Storey Prefabricated House | |
Main Steel Frame | |
Steel column | Fabricated by Q235 Steel, 80*80 or 100*100 or 120*120 or 150*150 Square Tube, alkyd paiting, two primary painting, two finish painting. |
Triangular Steel structure roof | Fabricated by Q235 Steel, C80, C100, C120, C140 Section steel, alkyd paiting, two primary painting, two finish painting. |
Roof Purlin | Fabricated by Q235 Steel, C80, C100, C120, C140 Section steel, alkyd paiting, two primary painting, two finish painting. |
Ordinary bolt | 4.8S,Zincification |
Roof and Wall | |
Roof Panel | Insulated Steel Sandwich Panel wall Panel width: 950mm; Thickness: 50-1200mm. Powder coated Color steel on both sides: 0.4mm/0.5mm/0.6mm Insulation: Polystyrene, Rockwool or Polyurethane Density of Rockwool: 120Kg/m3 Density of Polystyrene: 12Kg/m3, 16KG/M3 20KG/M3 Density of Polyurethane: 40Kg/m3 |
Wall Panel | Insulated Steel Sandwich Panel wall Panel width: 950mm; Thickness: 50-1200mm. Powder coated Color steel on both sides: 0.4mm/0.5mm/0.6mm Insulation: Polystyrene, Rockwool or Polyurethane Density of Rockwool: 120Kg/m3 Density of Polystyrene: 12Kg/m3, 16KG/M3 20KG/M3 Density of Polyurethane: 40Kg/m3 |
Edge cover | 0.4mmgalvanized Color steel , angle Alu. |
Fasteners & accessoreis | Nails\glue ect |
Ceiling+Flooring | |
Ceiling | 6mm gypsum board,with steel keel |
Plywood | 18mm film faced plywood |
Floor feather | 1.5mm PVC floor leather |
Door and window | |
Door | External door: Insulated with opening dimension 950*2100mm, furnished with lock with 3keys. Inner door: Insulated steel door. |
Window | PVC window witn 4mm glass, with screem |
Electrical System | |
Electric cable | Honyar brand, lighting 2.5m m2, aircondition: 4.0mm2, BV cable, solid core. Three diferent color |
PVC wire Channel | Honyar brand |
Lights | double tube fluorescent lamp, 220V,50-60HZ |
Switches | Honyar brand, Single Switch, with junction box |
Socket | 16A five hole univesal socket. |
Power distribution cabinet | Honyar brand, box+breakers+earth leakage protective device |
Plumbing System and Rain Water Drainage System As per building design |
Installation
1. you are manufacture factory or trading company?
A: We are manufacture factory. Welcomed to visit our factory in the city of Weifang.
2.Why Choosing prefab house?
There are many advantages to modular camp construction for site camps including:
(1) Easy to assemble and disassemble for several times without damage.
(2) Could be lifted, moved , and combined freely.
(3) Heatproof and waterproof.
(4) Cost saving and convenient transportation (Each 4 container house can loaded in one standard container)
3. Why we trust you?
(1) We have already passed the ISO,CE,SGS,BV certification.
(2) We are one of the suppliers for Chinese government key project.
(2) We are one main container house supplier for UN project. We could provide the project pictures and videos for your reference..
4.How could I install the prefab house?
There are two ways to solve the problem.
(1) We could provide the full services for the whole installation, included sending our engineers to your country to help the installation.
(2) If you do not need the construction supervision, we could provide the full services include the installation video, detailed drawings, and guide the installation through network step by step.
We welcome you to contact us for more information of
prefab house and look forward to working with you !
