New assembly house Supply for staff accommodation

Overview

Quick Details

Place of Origin:: Shandong, China

Brand Name:: LIDA

Model Number:: LDPF 036

Use:: Hotel, House, Office, Sentry Box,Guard House, Shop, Toilet, labor camp/refugee camp/dormitory/accommodation

Item:: 2 floor prefabricated house madagascar, prefabricated school building

Keywords:: prefabricated house modern

Frame Structure:: square steel tube or C channel or H-section steel

Wall and Roof:: Rock wool/Glass wool/EPS/PU sandwich panel

Service life:: more than 10 years

Fireproof:: 2-4 hours

Moveable/relocatable:: avaialble, with or without steel chassis

Steel anti-rust treatment:: painted or galvanized

House size:: customized

Installation:: supervisor guiding installation is available

Supply Ability

Supply Ability:: 50000 Square Meter/Square Meters per Month 2 floor prefabricated house

Product Description

China South Africa Greece Steel Prefabricated House Modern

Advantages:

1) Size is customized, design according to requirements.

2) Service life is up to 15 years.

3) Cost effective, the average price is from USD 60/sqm to USD 120/sqm.

4) Fast construction, from production to finishing installation, only need several months.

5) Green and Environmental, energy-saving, anti-fire, anti-earthquake, water proof.

Type	With or without steel chassis	Type one: without steel chassis, build on concrete strip foundation Type two: with steel chassis, the building will be put on concrete blocks
Type	Story	One storey or two storey or three storey are available
Frame system	Steel column	Q235 Steel, 1001002.5 square tube, alkyd painting, twice primer paint & twice finish paint
	Steel roof truss	C1004015*2.0, welding and galvanized
	Roof and wall purlin	C1004015*2.0, galvanized
	Cross bracing	Q235 Steel, L40*3 angle steel, alkyd painting, twice primer paint & twice finish paint
	Chemical bolt	M16, chemical bolt
	Ordinary bolt	4.8S, galvanized
Steel chassis or 1st floor system	Main beam	HN2501255.5*8, Q235 Steel, alkyd painting, twice primer paint & twice finish paint
	Secondary beam	C1004015*2.0 galvanized
	Floor structure board	18/20mm plywood and fiber cement board
	Flooring	PVC floor leather and ceramic tiles are available
Wall and Roof system	Wall panel	Sandwich panel: Rock wool, Glass wool, EPS, PU are available Thickness: 50mm, 75mm, 100mm, 150mm, 200mm are available
Wall and Roof system	Roof panel	Sandwich panel: Rock wool, Glass wool, EPS, PU are available Thickness: 50mm, 75mm, 100mm, 150mm, 200mm are available
Ceiling system	Dry room	6006006mm gypsum board,with framework
Ceiling system	Wet room	6006005mm calcium silicate board, with framework
Door and window system	Door	Fire resistant steel single/double door, emergency door with panic bar, aluminum glass door, MDF door are available
Door and window system	Window	PVC, Aluminum sliding window with single/double glazed glass, with mosquito screen, with louver are available
Electric and Plumbing system	Electric units	Electric wire, conduit, socket, switch, light, distribution box
Electric and Plumbing system	Sanitary units	Shower, closestool, basin, water pipe

Company Information

FAQ

Q: Are you factory or trading company?

A: Our Lida Group have main factory named Weifang Henglida Steel structure Co., Ltd., which is in Weifang city. Qingdao Lida construction Facility Co., Ltd. is in Qingdao city. Shouguang Lida Prefab House Factory is in Shouguang city, all of them are in Shandong province.

Q: How about your production capacity?

A: Pre engineered steel structure building (warehouse/workshop/hangar/shed/high rise apartment): 50000 sqm monthly. Prefabricated house (portacabin/labor camp/site office): 100000 sqm monthly. Prefab affordable house (low cost family/residential/refugee): 4200 units monthly. Container house: 800 units monthly. Light steel villa: 10000 sqm monthly.

Q: How about your quality control?

A: We have got certificate ISO9001:2015, certificate CE EN 1090. Products processing through cutting, bending, welding, shot blasting, ultrasonic testing, packing, storing, loading to ensure no quality defects.

Q: Is third party inspection available?

A: SGS, BV, TUV, etc. are available, it is according to client requirement.

Q: How about your delivery time?

A: Generally within 30 days, it is according to order quantity, partial shipment is allowed for big order.

Q: What about the installation?

A: We'll provide the detailed installation drawing, supervisors guiding installation is available. We can do turnkey job for some kind of projects.

Q: How to ensure the product you supply is what we want exactly?

A: Before placing order, our sales and engineers team will provide you the suitable solution according to your requirements. Proposal drawing, Shop drawing, 3D drawing, Materials photos, Finished projects photos are available, which will help you understand the solution we provided deeply.

With rich industry experience, Lida Group continuously improves the production management system and cost management system. The prefab house we produce is superior to other similar products whether in appearance, performance, quality, or price. Lida Group has large-scale production plants, modern production equipment, intelligent production lines, senior designers and engineers. Besides, we have established scientific and standardized production processes and professional and rigorous quality assurance system. Our production strength is unanimously recognized in the industry. Our prefab house has stable performance and excellent quality.

t******u

Lida Group assembly house contains many delicate manchineel parts. These components include pumps, compressors, generators and other welded and welded components. Wide measurement range to cater for different applications

b******d

Lida Group assembly house is professionally designed. Its design includes material design, system design, mechanical design and component structure design. When emergencies happen, it can discharge residual reactants and resume working status automatically

f******g

The mechanical parts of Lida Group assembly house have to go through strict fabrication. They have to undergo casting, cutting, thermal treating, surfacing polishing, etc. It is highly resistant to chemical substances such as alkali and acid

f******o

The designed of Lida Group assembly house is sophisticated. It is developed by professionals who have been involved in the characterization, Mechanical design, and development of advanced technology products for years. Waterproof and durable construction for use in harsh environments

v******v

Lida Group assembly house must be tested to be in compliance with general standards. It has been tested for machinery directive, operation safety, and life expectancy. Auto shut-off feature to conserve battery life

t******w

assembly house is relatively assembly house and has been designed for higher performance. It supports multi-channel measurements in water samples
