Newest Modern style prefabricated house,light steel villa for the appartement

这里可以自定义设置
Newest Modern style prefabricated house,light steel villa for the appartement
B站不支持收货地址
B站不支持库存规格
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
Lida
Model Number:
Lida LGS villa
main material:
light steel and sandwich panel
size:
customized
transport:
container or as you requirement
certificate:
CE&ISO
Modern LGS Villa House:
Modern LGS Villa House
Supply Ability
Supply Ability:
100 Set/Sets per Month

    Innovative stylish design  light steel prefabricated villa


Product Description

Brazil light steel villa with CE/ISO certification

Specifications

light steel structure simple villa projects is easy to assemble and disassemble for several times and cost saving and transport

Light steel structure simple villa projects

(1) Light steel structure modular house.

(2) Wall panels and roof panels are color steel sandwich panels

(3) Doors, windows and interior partitions fixed flexibly

(4) Easy to assemble and disassemble for several times without damage

(5) Cost saving and transportation convenient

(6) Anti-rust and normally more than 50 years using life



Technical Parameter of standard prefabricated house:

(1).Wind resistance: Grade 11(wind speed≤111.5km/h)

(2).Earthquake resistance: Grade 7

(3).Live load capacity of roofing: 0.5kn/m2

(4).External and internal wall heat transmission coefficient: 0.35Kcal/m2hc

(5).Second Floor Load Capacity: 150 kg/m2

(6).Live load of corridor is 2.0kn/ m2

We can design and produce the house according to customer’s request



Main Material (for standard house):

No.

Part name

Material name

Description



1

ground channel

C shape steel

C80x40x15x2.0



2

column

Double C shape steel

2C80x40x15x2.0 welded



3

Beam for second floor

Steel frame

2C80x40x15x2.0,L40x4 welded



4

Sub-beam for second floor

C shape steel

C80x40x15x2.0



5

Purlin for roof

Corner steel

L40x4



6

Bracing for roof

Corner steel

L40x4



7

Bracing for aisle and rain shelter

C shape steel

C80x40x15x2.0 welded



8

Bracing between the columns

Round steel,bolt

φ8



9

Step board

Steel board

t=3.0mm



10

stair

Steel stairs





11

Wall panel

V950 EPS sandwich panel

50mm thickness,steel plate:0.3mm



12

Partition panel

V950 EPS sandwich panel

50mm thickness, steel plate:0.3mm





13

Roof panel

V950 EPS sandwich panel

50mm thickness, steel plate: 0.3mm



14

Floor for second storey

plywood

16mm thickness



15

Rain shelter

One layer color steel plate

0.45mm thickness



16

windows

PVC sliding windows

0.93mx1.715m



17

door

Sandwich panel door

0.85mx2.1m



18

Entensive and commonbolt



Different dimension





Please contact us for further more information.


Our Services



1. Professional design and engineering team: Full solution for site camp design. We could make the design for whole camp as per your requirement.

2. Procurement and Manufacture for all material for prefabricated building. We have a professional procurement team to make sure all the materials are with good quality. And our factory operation under ISO standard, to make sure the fabrication works with high technology.

3. Site management & Installation supervision, We could send our engineers to help for the installation supervision, you just need to prepare a team which know normal construction works will be OK.


FAQ



Why choose LIDA LGS building? Our Lida modular house has  the following advantages

(1).Safer: The premium physical and chemical performance of steel is better than other structural styles. Steel performs better in disasters such as earthquake, typhoon etc, so the use of steel structure is safer.

(2).Durable: LGS housing is made from anti-corrosion and high strength galvanized or aluminium galvanized steel. The structure is more durable and there is no need to worry about contribution to a fire.

(3).Comfortable: The steel structure is moisture proof and insect proof. The living environment is more secure and comfortable.

(4).Flexible: All pipes can be concealed in the walls or floor structure. The actual usage area is at least 5% more than traditional concrete buildings. The different living areas can be divided freely according to the design requirement and won’t be restricted by the position of the load bearing walls.

(5).Energy Saving: The Composite light weight and high strength floor and wall materials are insulated reducing noise and saving a lot of money in energy costs.

(6).Environment Friendly: 100% light gauge housing frame is recyclable. There is no environmental pollution concern.

(7).Design Flexibility: Light gauge steel construction can accommodate almost any style of residential buildings up to 3 floors. If it can be built with concrete, it can be built with steel.

(8).Low Cost: Compared with concrete or other types of structures, a light gauge steel structure is light, and reduces the requirement on foundation loads, which can result in large scale savings in foundation costs.

(9).Speed up: All the parts can be pre-fabricated in the factory and are quick to install. The sequence of design makes it possible to construct both internal and external walls simultaneously, which speeds up construction.

(10).Quick Capital Turnover: The quick installation won’t tie up developers’ investment and can speed up retrieving capital and so reduce the investment risk and improve the investment benefit.

(11).Environment Friendly: Dry construction has little environmental pollution, as all parts are connected by screws. Construction is not affected by the season, and can continue in winter. There is little scrap left on site and no water is required in the construction process. 100% light gauge housing frame is recyclable.





Thanks for your attention! Any more questions, please don't be hesitant to contact me.                                Best regards and wish you a nice day!   (Welcome to our office and factory!)
One fantastic advantage of this product is the environmental benefit. It is eco-friendly and helps one reduce carbon footprint. This product stands out for t its good waterproofness. The popularity of this product seems to be increasing with the emergence of fashion trends such as container houses, container shopping stores, and container bars. This product stands out for t its good waterproofness.
