prefab container house with toilets for mining camp classroom dormitory

这里可以自定义设置
prefab container house with toilets for mining camp classroom dormitory
B站不支持收货地址
B站不支持库存规格
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障
Overview
Quick Details
Warranty:
3 years
After-sale Service:
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts
Project Solution Capability:
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
Place of Origin:
Shandong, China
Brand Name:
LIDA
Model Number:
LDKAL 3CONTAINER 20
Size:
Height=2.896m
Insulation:
75mm thickness fiber glass sandwich panel
Certificate:
CE EN1090,BV,SGS,ISO9001
Service time:
over 20 years
Usage:
living,work,washing,dinning,kitchen,bath
Application:
accommodation,construction site office
Feature:
fast assemble,stable withstand 250km/h wind
Keywords:
name:
prefab house

Packaging & Delivery

Selling Units:
Single item
Single package size:
60.55X24.35X4.25 cm
Single gross weight:
2000.000 kg
Package Type:
Big items such as finished Roof and floor,wall panels are in bulk plus protection material, Little items such as bolts,washers and so on,are packed in box.
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 25 26 - 100 >100
Est. Time(days) 25 35 To be negotiated

prefab container house with toilets for mining camp classroom dormitory

Product discription

 Advantages:

(1). Environment protective, no garbage caused
(2). Doors, windows and interior partitions can be flexibly fixed
(3). Beautiful appearance, different colors for the wall and roof.
(4). Cost saving and transportation convenient
(5). Anti-rust and normally more than 15 years using life
(6).Safe and stable, can stand 8 grade earthquake.





Items&Project Show
. Main Steel Frame
Steel  column Fabricated by Q235 or Q345 Steel,   80*80 or 100*100 or 120*120 or 150*150 Square Tube, alkyd paiting, two primary painting, two finish painting.
Triangular Steel structure roof Fabricated by Q235 or Q345 Steel, C80, C100, C120, C140 Section steel,  alkyd paiting, two primary painting, two finish painting.
Roof Purlin Fabricated by Q235 Steel, C80, C100, C120, C140 Section steel,  alkyd paiting, two primary painting, two finish painting.
Ordinary bolt 4.8S, Galvanized
2. Roof and Wall
Roof Panel

A: Insulated Steel Sandwich Panel wall
(1) Panel width: 950mm;
(2) Thickness: 50-1200mm.
(3) Powder coated Color steel on both sides:  0.4mm/0.5mm/0.6mm


B: Insulation: Polystyrene, Rockwool, Fiber Glass or Polyurethane
(1) Density of Rockwool: 120Kg/m3
(2) Density of Polystyrene: 12Kg/m3, 16KG/M3 20KG/M3
(3) Density of Polyurethane: 40Kg/m3
(4) Density of Fiber Glass:40Kg/m3, 60Kg/m3

Wall Panel

A: Insulated Steel Sandwich Panel wall
(1) Panel width: 950mm;
(2) Thickness: 50-1200mm.
(3) Powder coated Color steel on both sides:  0.4mm/0.5mm/0.6mm


B: Insulation: Polystyrene, Rockwool, Fiber Glass or Polyurethane
(1) Density of Rockwool: 120Kg/m3
(2) Density of Polystyrene: 12Kg/m3, 16KG/M3 20KG/M3
(3) Density of Polyurethane: 40Kg/m3
(4) Density of Fiber Glass:40Kg/m3, 60Kg/m3

Edge Cover 0.4mm galvanized color steel , angle Alu.

Fasteners &

Accessoreis

Nails\glue ect
3. Ceiling&Flooring
Ceiling 6mm gypsum board,with steel keel
Plywood 18mm film faced plywood
Floor feather  1.5mm  PVC floor leather
Door and window
Door  (1) External door: Single open door. Insulated with opening dimension 950*2100mm, furnished with lock  with 3keys.
(2) Inner door: Single open door. Insulated steel door.
Window 4mm glass PVC window witn flying screem
4. Electrical System
Electric Cable (1) Three diferent color.
(2) Lighting: 2.5m m2.
(3) Air condition: 4.0mm2.
(4) BV cable, solid core.
PVC Wire Channel PVC wire channel
Lights   Double tube fluorescent lamp, 220V,50-60HZ
Switches Single Switch, with junction box
Socket 16A five hole univesal socket.
Power Distribution Cabinet Box+breakers+earth leakage protective device
5. Water&Plumbing system(choose)
Water drain pipe (1) PPR pipe, dim 16-20mm, connection fittings are made of copper, life span over 10 years.
(2) Exhaust fan or air exchange hole, size 250mm*250mm made of steel or PVC
Sanitary ware (1) Western Close tool: ceramic, with pipes and installation fittings
(2) Urinal: ceramic, with pipes and installation fittings
(3) Wash basin: ceramic, with post, faucet, pipes and installation fittings
(4) Shower head, Shower base, Water mixture
6. Plumbing System and Rain Water Drainage System as per building design



Related Products









FAQ


Q: Are you factory or trading company?

A: Our Lida Group have main factory named Weifang Henglida Steel structure Co., Ltd., which is in Weifang city. Qingdao Lida construction Facility Co., Ltd. is in Qingdao city. Shouguang Lida Prefab House Factory is in Shouguang city, all of them are in Shandong province.



Q: How about your production capacity?

A: Pre engineered steel structure building (warehouse/workshop/hangar/shed/high rise apartment): 50000 sqm monthly. Prefabricated house (portacabin/labor camp/site office): 100000 sqm monthly. Prefab affordable house (low cost family/residential/refugee): 4200 units monthly. Container house: 800 units monthly. Light steel villa: 10000 sqm monthly.



Q: How about your quality control?

A: We have got certificate ISO9001:2015, certificate CE EN 1090. Products processing through cutting, bending, welding, shot blasting, ultrasonic testing, packing, storing, loading to ensure no quality defects.



Q: Is third party inspection available?

A: SGS, BV, TUV, etc. are available, it is according to client requirement.



Q: How about your delivery time?

A: Generally within 30 days, it is according to order quantity, partial shipment is allowed for big order.



Q: What about the installation?

A: We'll provide the detailed installation drawing, supervisors guiding installation is available. We can do turnkey job for some kind of projects.



Q: How to ensure the product you supply is what we want exactly?

A: Before placing order, our sales and engineers team will provide you the suitable solution according to your requirements. Proposal drawing, Shop drawing, 3D drawing, Materials photos, Finished projects photos are available, which will help you understand the solution we provided deeply.

FAQ


Lida Group has established container house production base to meet the steady increasing requirement of domestic prefab house manufacturing industry. This product combines simplicity with utility. Lida Group has created new market highlights for prefab house. This product combines simplicity with utility.
