Prefab Office Container Complex

Product Introduction

Flat pack container house is made by steel frame structure, which adopts cold-form galvanized steel. Structure is consists of three modular parts: roofing frame, corner column and floor frame. Each modular is manufactured at the factory and assembled on construction site.  With one single container house as basic unit, it can be combined horizontally or vertically in different form like building blocks. Flat pack container house can be stacked in three storeys with flexible in space layout and multiple function, and can be used in different application fields.

Manufacturing Technology

The production process introduces advanced design concept, production material has adopt double side full-color steel sandwich panel. PU foam panel, bolt, aluminum fittings, concrete, wood, ceramic tile. The flat pack container house can be used confortably for anytime anywhere.

Main Features

1) Easily Installed and transported.

2) Economical and Sustainable.

3) Safe and durable. It is anit-earthquake 8 grades, wind resistant 12 grades, and the service life will more than 20 years.

4) Thermal Insulation.

5) Customized Combination.  it can be connected in vertical and horizontal direction.

Main Features

Transport Convenience

Dimension of flat pack contaner house is 6055mm length, 2435mm or 3000mm width. The dimension not exceeds the regulation size of land transport.

Corner part is products based on ISO shipping container specification, it can be transport as standard shipping container. Also the container house can be lift by handle corner part during installation process.

For shipping, it can be loaded into 40frt HQ shipping container and one container can load 6 units.
