Prefab steel structure warehouse plant frame buildings hangar

这里可以自定义设置
Prefab steel structure warehouse plant frame buildings hangar
B站不支持收货地址
B站不支持库存规格
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
Lida
Model Number:
PH-001
Use:
Hotel, House, Kiosk,Booth, Office, Sentry Box,Guard House, Shop, Toilet
color:
blue & red top / white wall
column:
C section steel/ 2C80
buiding height:
max 3 floors
anti-seismic:
7 degree
certificate:
CE/ISO/SGS
prefab design portable house:
prefab design portable house
Product name:
structure steel
Supply Ability
Supply Ability:
5000 Square Meter/Square Meters per Day prefabricated steel structure building

Product Description

Prefab steel structure warehouse plant frame buildings hangar



Materials:

1. The main frame (columns and beams) is made of welded H-style steel.

2. The columns are connected with the foundation by pre-embedding anchor bolt.

3. The beams and columns, beams and beams are connected with high intensity bolts.

4. The envelop construction net is made of cold form C-style purlins.

5. The wall and roof are made of color steel board or color steel sandwich panels, which are connected with the purlin by Self-tapping nails.

6. Doors and windows can be designed at anywhere which can be made into normal type, sliding type or roll up type with material of PVC, metal, alloy aluminium, sandwich panel and so on.



1. Steel Structure Buildings Introduction:

Light steel structure building is widely used as large factory, warehouse, workshops, bridges, stadiums and other buildings. Light steel structure warehouse building is a new type of building structure system, which is formed by the main steel framework linking up H-section, Z-section, and U-section steel components, roof and walls using a variety of panels and other components such as windows and doors.



2. Steel Structure Buildings Characteristics:

1.Wide span: single span or multiple spans, the max span is 36m without middle column
2.Low cost: unit price range from USD35/m2 to USD70/m2 according to customers request
3. Fast construction and easy installation
4. Long using lifespan: up to 50 years
5.Others: environmental protection, stable structure, earthquake resistance, water proofing, and energy conserving.









tructure    H-section steelQ345 steel H beam, Box column is also available
WeldingAutomatic Submerged Arc Welding
Rust removingShot blasting
surface processing

twice primer and twice finish Alkyd Paint or hot dip

galvanized

High strength boltGrade 10.9
Substructure    Angle braceL50x4,Steel Q235,Process and painting
Cross bracingDia.20 round bar,Steel Q235, process and pre-galvanized
Tie bar

Dia.89*3 round pipe,Steel Q235 Process and painting

or pre-galvanized

Batter brace

Dia.12 round bar,Steel Q235 process and

pre-galvanized

Ordinary boltGalvanized bolt
Roof      PurlinC channel or Z channel,steel Q235, galvanized
Roof panel

(50mm, 75mm, 100mm, 150mm) Sandwich panel or

corrugated GI color steel sheet

Transparent

skylight

1.2mm FRP
AccessoriesSealant, self-tapping screw, etc.
Edge coverMade of color steel sheet
GutterMade of steel sheet thickness 0.8mm, or PVC
RinspoutPVC pipe
Wall   PurlinC channel or Z channel, steel Q235, galvanized
Wall panel

(50mm, 75mm, 100mm, 150mm) Sandwich panel or

(0.4mm, 0.5mm, 0.6mm, 0.7mm) corrugated GI

color steel sheet

AccessoriesSealant, self-tapping screw etc
Edge coverMade of GI color steel
Ventilator unpowered axial-flow ventilator or monitor roof
Door & window Electric rolling door/sliding door, PVC/Alu. alloy window
Crane With or without crane, ranging from 5 tons to 20 tons



Related Products

Company Information


FAQ


Q: Are you factory or trading company?

A: Our Lida Group have main factory named Weifang Henglida Steel structure Co., Ltd., which is in Weifang city. Qingdao Lida construction Facility Co., Ltd. is in Qingdao city. Shouguang Lida Prefab House Factory is in Shouguang city, all of them are in Shandong province.



Q: How about your production capacity?

A: Pre engineered steel structure building (warehouse/workshop/hangar/shed/high rise apartment): 50000 sqm monthly. Prefabricated house (portacabin/labor camp/site office): 100000 sqm monthly. Prefab affordable house (low cost family/residential/refugee): 4200 units monthly. Container house: 800 units monthly. Light steel villa: 10000 sqm monthly.



Q: How about your quality control?

A: We have got certificate ISO9001:2015, certificate CE EN 1090. Products processing through cutting, bending, welding, shot blasting, ultrasonic testing, packing, storing, loading to ensure no quality defects.



Q: Is third party inspection available?

A: SGS, BV, TUV, etc. are available, it is according to client requirement.



Q: How about your delivery time?

A: Generally within 30 days, it is according to order quantity, partial shipment is allowed for big order.



Q: What about the installation?

A: We'll provide the detailed installation drawing, supervisors guiding installation is available. We can do turnkey job for some kind of projects.



Q: How to ensure the product you supply is what we want exactly?

A: Before placing order, our sales and engineers team will provide you the suitable solution according to your requirements. Proposal drawing, Shop drawing, 3D drawing, Materials photos, Finished projects photos are available, which will help you understand the solution we provided deeply.

Lida Group has professional design team and production team. Besides, we have advanced production technology and sophisticated production equipment. All this provides a strong guarantee for the high quality of prefab house. Designed by professionals, prefab house is manufactured based on high-quality steel. Besides, it is tested by relevant national inspection departments. It is guaranteed to be in line with national quality standards.
