Overview

Quick Details

Warranty:: 3 years

After-sale Service:: Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement, NONE

Project Solution Capability:: graphic design, 3D model design, total solution for projects, Cross Categories Consolidation, NONE

Place of Origin:: Shandong, China

Brand Name:: LIDA

Model Number:: LD-C044

Use:: Carport, Hotel, House, Kiosk,Booth, Office, Sentry Box,Guard House, Shop, Toilet, Villa, Warehouse, Workshop,Plant, modular building

Product Type:: Container Houses

Item:: prefabricated container office

Keywords:: container modular room

Product name:: office container 40 ft

Storey:: 1 or 2 or 3 storey are available

Flat pack:: all materials packed to be rectangular box

Loading:: SOC or loaded in 40ft HQ shipping container

After Sales Service:: 15 Years

Fireproof:: resistant 3 hours

Waterproof:: new technology to provide good waterproof performance

Installation:: supervisor guiding, video are available

Supply Ability

Supply Ability:: 800 Unit/Units per Month flat pack building

Prefabricated container office container modular room container homes

Product Description

Brief Description

LIDA flat pack container house is ideally suited for construction sites, construction camps and drilling camps, where they will be advantageously turned into offices, living accommodations, changing rooms and toilet facilities.

LIDA flat pack container house are made of natural materials and are almost 100% recyclable. They deliver great environmental benefits (thermal insulation, sound reduction) to present an adaptable, versatile, and sustainable modular solution

LIDA flat pack container house can be shipped assembled or to keep transport cost to a minimum, supplied flat-packed for on-site installation with just the minimum of tools. LIDA flat pack container house can also be easily disassembled after use and transferred to a new location.

Detailed Specification

Specification	1) 20ft: 605524352896mm
	2) 40ft: 1219224352896mm
	3) Roof Type: Flat roof with organized internal water draining design
	4) Storey: ≤3
Design parameter	1) Life span: up to 20years
	2) Floor Live load: 2.0KN/m2
	3) Roof Live load: 0.5KN/m2
	4) Wind load: 0.6KN/m2
	5) Earthquake-resistance: Grade 8, Fire-proof: Grade 4
Wall panel	1) Thickness: 75mm fiber glass sandwich panel, effective width: 1150mm
	2) Exterior steel sheet (standard configuration): Corrugated 0.4mm Aluminum-zinc color steel sheet, PE finishing coat, Color: white, Aluminum-zinc thickness≥40g/m2
	3) Insulation layer (standard configuration): 75mm Fiber glass, density≥50kg/m3, Fire-proof standard: grade A non-flambable
	4) Interior steel sheet(standard configuration): Flat 0.4mm Aluminum-zinc color steel sheet, PE finishing coat, Color: white, Aluminum-Zinc thickness≥40g/m2
Roof system	1) Steel frame & accessories: Main roof frame: cold formed steel, thickness=2.5mm, galvanized. with 4pcs galvanized lifting corners. Roof purlin: C804015*2.0, galvanized. Q235B steel
	2) Roof panel: 0.4 or 0.5mm thickness Aluminum-zinc color steel sheet, PE finishing coat. Color: white, Aluminum thickness≥70g/m2, 360° full connection
	3) Insulation: 100mm thickness Fiber glass with aluminum foil, Density=14kg/m3, Grade A fire-proof, nonflammable.
	4) Ceiling board: V-170 type, 0.5mm Aluminum-zinc color steel sheet, PE finishing coat. Color: white, Aluminum-zinc thickness≥40g/m2.
	5) Industrial socket: Fixed in explosion-proof box at the top beam of the short side, with 1 main power plug for power connection between containers
Corner pillar	1) Cold rolled steel: 4pcs pillar with same dimension, thickness=3mm, steel grade Q235B.
Corner pillar	2) Corner pillar and main frame are joined by hexagon socket head bolt, strength: grade 8.8. Filled with Fiberglass insulation
Floor System	1) Steel structure & accessories: Main floor frame: cold formed steel, thickness 3.5mm, galvanization; Floor purlin:C1204015*2.0, galvanized. Q235B steel. Standard container is Without forklift hole, it can be added according to customer's requirement.
	2) Insulation (optional): 100mm thickness Fiber glass with aluminum foil, Density=14kg/m3. Flammability:grade A, nonflammable.
	3) Bottom covering (optional): 0.25mm color steel sheet, Zinc thickness≥70g/m2.
	4) Floor board: 18mm thickness fiber cement board, Fire-proof:grade B1. Density≥1.3g/cm3
	5) Interior Flooring: 1.5mm thickness PVC leather, Blue marble color
Door & Window	1) Insulated light steel door: Entrance door is W850H2030mm, Toilet door is W700H2030mm.
Door & Window	2) PVC sliding window, double glass 5mm thickness, with mosquito screen and security bar. Standard window: W800H1100mm(for 2.4meter's container), W1130H1100mm(for 3 meter's container), Toilet window: W800*H500mm
Electric system	1) Rated power: 5.0 KW, suggestion external power source ≤3 in series.
	2) Technical parameters: CEE industrial plug, socket voltage 220V- 250V, 2P32A, Fixed in explosion-proof box at the top beam of the short side, the electric cable in the roof is protected by PVC pipe with CE certification; Using IP44 standard power distribution box.
	3) Electrical data: main power cable is 6 mm2, AC cable is 4 mm2, socket cable is 2.5 mm2, lighting & switch cable is 1.5 mm2. Five sockets, 1pc AC socket of 3holes 16A, 4pcs socket of 5holes 10A. 1pc single connection switch, 2pcs double tube LED light, 2*15W.
Painting	1) Primer painting: epoxy primer, Zinc color, thickness: 20 - 40 μm.
Painting	2) Finishing paint: Polyurethane finishing coat, white color, thickness: 40-50 μm. Total paint film thickness≥80μm. Galvanized components, galvanized layer thickness≥10μm (≥80g/m2)

20ft Flat pack container house

40ft Flat pack container house

Production photos

Project Photos

Packaging & Shipping

Our Services

1) Professional sales team: all staff are bachelor and master, abroad team in Saudi Arabia, Qatar, Dubai, Kuwait, Maldives, Malaysia, Sri lanka, etc., provide the best communication.

2) Professional engineers team: all staff are master and doctor, provide the best engineering and solution.

3) Professional fabrication: all workers are through professional training, provide the quality guarantee products.

4) Professional installation team: supervisors guide installation from 2004 with rich experience.

5) Turnkey is also available for some projects.
