Qingdao 20 ft / 16 ft light steel collapsible storage container

这里可以自定义设置
Qingdao 20 ft / 16 ft light steel collapsible storage container
B站不支持收货地址
B站不支持库存规格
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
Lida Group
Model Number:
LD-C-01
Material:
Steel
Product name:
Prefab Warehouse
Door:
Steel Door
Window:
Steel Window
Roof:
Sandwich Panel. Single Steel Sheet
Main frame:
Steel Truss
Wall:
50mm/75mm Sandwich Panel
Standard:
ISO standard 20ft, 40ft are available
Type:
flat pack container and shipping container
Certificate:
ISO9001/SGS/CE/BV
Supply Ability
Supply Ability:
800 Set/Sets per Month



Product Description



LIDA container house includes two types:

The first one is LIDA flat pack container house.
The second one is LIDA Welding/Shipping container house.
1)  LIDA flat pack container house is ideally suited for construction sites, construction camps and drilling camps, where they will be advantageously turned into offices, living accommodations, changing rooms and toilet facilities.
LIDA flat pack container are made of natural materials and are almost 100% recyclable. They deliver great environmental benefits (thermal insulation, sound reduction) to present an adaptable, versatile, and sustainable modular solution. LIDA flat pack container can be shipped assembled or to keep transport cost to a minimum, supplied flat-packed for on-site installation with just the minimum of tools. LIDA flat pack container can also be easily disassembled after use and transferred to a new location.

2)  LIDA Welding/Shipping container house is widely used as Holiday house, Vacation house, Beach house, Hotel, Restaurant, Bar, Club, Coffee shop, etc. There are a lot of choice for outside color and a lot of choice for inside decoration, it can be decorated pretty beautiful. Everything are fixed in factory, can be used directly after arrival at destination.

LIDA flat pack container house



Specification

1) 20ft: 6055*2435*2896mm; 40ft: 12192*2435*2896mm

2) Roof Type: Flat roof with organized internal water draining design

3)  Storey: ≤3



Design parameter

1)  Life span: up to 20years

2) Floor Live load: 2.0KN/m2;Roof Live load: 0.5KN/m2;Wind load: 0.6KN/m2

3)  Earthquake-resistance: Grade 8, Fire-proof: Grade 4













Steel Structure System

1) Roof structure:6055*2435*200mm, Main roof frame: thickness=2.5mm, height=180mm, galvanization thickness≥40g/m2, Q235 steel; Roof purlin: C80*40*15*2.0, galvanized, Q235 steel

2) Floor structure:6055*2435*180mm, Main floor frame: thickness 3.25mm, height 160mm, galvanization thickness≥40g/m2, Q235 steel; Floor Purlin:C120x50(30)x12x2.0, galvanized. Q235 steel

3) Corner pillar:210*150*30mm, length=2535mm, thickness=2.75mm, galvanization thickness≥40g/m2. Q235 steel

4) Paint:Epoxy primer & Polyurethane finishing coat, paint film thickness ≥80μm, white color





Wall panel

1) Wall panel:V-1150 type, 75mm Fiber glass sandwich panel with 0.4mm color steel sheet on both sides(white color), insulation density=45 kg/m3

2) Door:Light steel single open door (W850*H2030mm)

3) Window:PVC sliding window, double glass 4mm thickness, with screen and security bar (W800*H1100mm)











Roof &Floor system

1) Roof covering:0.4mm color steel sheet, white color

2) Insulation:100mm thickness Fiber glass with aluminum foil, Density=12kg/m3

3) Ceiling board:V-196 type, 0.4mm Aluminum-zinc color steel sheet, white color

4)PVC flooring:1.8mm thickness plastic floor with glue

    Floor board:18mm thickness fiber cement board

5)  Insulation: 100mm thickness Fiber glass with aluminum foil, Density=12kg/m3

      Bottom covering:0.25mm color steel sheet, Zinc thickness≥40g/m2





Corner pillar

1) Cold rolled steel: 4pcs pillar with same dimension, thickness=3mm, steel grade Q235B.

2) Corner pillar and main frame are joined by hexagon socket head bolt, strength: grade 8.8. Filled with Fiberglass insulation



Electrical System

1) Industrial plug:power input industrial socket, 32A Honyar brand

2) Light ; AC socket; Socket; Switch



Flashing

1) Long side flashing:Length=5635mm, thickness=1mm, galvanized

2) Short side flashing:Length=2690mm, thickness=1mm, galvanized

Drainage system

Rainspout pipe:Dia. 50mm, UPVC, Length=2600mm







Trim plate

1) Pillar trim plate:Length=2600mm, 0.5mm color steel plate(with fittings & accessories)

2) Ceiling trim plate:Length=5640mm/2630mm, 0.5mm color steel plate(with fittings & accessories)

3) Skirting:Length=5850mm/2850mm, PVC (with fittings & accessories)

Inland transportation:1*40ft HQ container could load 6 sets this house



LIDA Welding/Shipping container house

Welding container

1.5mm corrugated steel sheet, 2.0mm steel sheet, column, steel keel, insulation, floor decking

Type

20ft: W2438*L6058*H2591mm (2896mm is also available)
40ft: W2438*L12192*H2896mm

Ceiling and Wall inside decoration board

1) 9mm bamboo-wood fiberboard  2) gypsum board

Door

steel single or double door or PVC/Aluminum glass sliding door

Window

1) PVC sliding (up and down) window 2) Glass curtain wall

Floor

1) 12mm thickness ceramic tiles (600*600mm, 300*300mm)  2) solid wood floor 3) laminated wood floor

Electric units

CE, UL, SAA certificate are available

Sanitary units

CE, UL, Watermark certificate are available

Furniture

Sofa, bed, kitchen cabinet, wardrobe, table, chair are available



FAQ




Q: Are you factory or trading company?

A: Our Lida Group have main factory named Weifang Henglida Steel structure Co., Ltd., which is in Weifang city. Qingdao Lida construction Facility Co., Ltd. is in Qingdao city. Shouguang Lida Prefab House Factory is in Shouguang city, all of them are in Shandong province.



Q: How about your production capacity?

A: Pre engineered steel structure building (warehouse/workshop/hangar/shed/high rise apartment): 50000 sqm monthly. Prefabricated house (portacabin/labor camp/site office): 100000 sqm monthly. Prefab affordable house (low cost family/residential/refugee): 4200 units monthly. Container house: 800 units monthly. Light steel villa: 10000 sqm monthly.



Q: How about your quality control?

A: We have got certificate ISO9001:2015, certificate CE EN 1090. Products processing through cutting, bending, welding, shot blasting, ultrasonic testing, packing, storing, loading to ensure no quality defects.



Q: Is third party inspection available?

A: SGS, BV, TUV, etc. are available, it is according to client requirement.



Q: How about your delivery time?

A: Generally within 30 days, it is according to order quantity, partial shipment is allowed for big order.



Q: What about the installation?

A: We'll provide the detailed installation drawing, supervisors guiding installation is available. We can do turnkey job for some kind of projects.



Q: How to ensure the product you supply is what we want exactly?

A: Before placing order, our sales and engineers team will provide you the suitable solution according to your requirements. Proposal drawing, Shop drawing, 3D drawing, Materials photos, Finished projects photos are available, which will help you understand the solution we provided deeply.

The product has a direct relationship with people's physical and mental health. People are less likely to suffer from microbial diseases caused by this product. This product has been designed to last for decades. The product requires little maintenance. It features little need for cleaning. People can wipe the dirt or stain only using a damp cloth. This product has been designed to last for decades.
