Lida Group China Prefabricated House Supplier | One-stop Solution for Modular House, Container House!     Marketing@lidajituan.com

Top modular homes with garages factory for staff accommodation 1
Top modular homes with garages factory for staff accommodation 1

Top modular homes with garages factory for staff accommodation

Inquiry

Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
LIDA
Model Number:
LDP2016
Main Materials:
Q235 Steel,steel square tube
Wall and Roof:
Sandwitch panel
Size:
Custom Required
Feature:
cheaper,multiduty,easy installation,recyclable
Certificate:
ISO9001,EN1090,BV,SGS
Standard:
GB
Application:
Office,domitory,toilet,bathroom etc.
Usage:
living,work,washing,rent etc.
Color:
Customized
keywords:
prefab house turkey
Supply Ability
Supply Ability:
50000 Square Meter/Square Meters per Week

2 bedroom 3 storey prefab house turkey

Product Description



Prefabricated House

Prefabricated house is made of light steel as steel structure and sandwich panels for wall and roof. The sandwich panels can be polystyrene, polyurethane, rock wool and fiber glass sandwich panels for insulation. As a standardized construction product, it has below main features: Dry installation, no construction garbage caused; Environment protective materials adopted, repeated use and low cost; Flexible size and easy to assemble and disassemble with elegant appearance; Safe and durable. It is suitable for temporary buildings such as dormitory, canteen, recreation room, washing room, etc.



Technical Parameter of standard prefabricated house:

1. Wind resistance: Grade 11(wind speed111.5km/h)

2. Earthquake resistance: Grade 7

3. Live load capacity of roofing: 0.5kn/m2

3. External and internal wall heat transmission coefficient: 0.35Kcal/m2hc

4. First floor load capacity: 150 kg/m2

5. Live load of corridor is 2.0kn/ m2

6. Four skilled workers can finish installation of 100sqm in 8 hours for the light steel structure.

7. Most components of the house are recycled, so the shelf life is over 20 years without any building garbage.

8. We can design and produce the house according to customer’s request.

9. We can provide the service of installation, supervision and training by extra.



No.



ItemSpecification & Remark
1



Steel Structure



Q235 steel (painting)

Square Tube columns, C section steel purlin and  roof truss etc.

2



Roof panel



75mm EPS panel with 0.4mm galvanized color steel on both sides, density for EPS is 12kg/m3

(or other materials such as rock wool panel,fiber glass panel etc.Thickness could be 50mm,75mm or 100mm.)

3



Exterior wall panel



75mm EPS panel with 0.4mm galvanized color steel on both sides, density for EPS is 12kg/m3

(or other materials such as rock wool panel,fiber glass panel etc.Thickness could be 50mm,75mm or 100mm.)

4



Interior wall panel



50mm EPS panel with 0.4mm galvanized color steel on both sides, density for EPS is 12kg/m3

(or other materials such as rock wool panel,fiber glass panel etc.Thickness could be 50mm,75mm or 100mm.)

5



Door



Sandwich panel door
6



Windows



PVC sliding window
7



Ceiling



6mm Gypsum /
12mm PVC

8



flooring for first floor



18mm Plywood
9



First floor covering



1.5mm PVC floor leather
10



Accessories



0.4mm Galvanized color steel edge cover, self-screws, bolts and so on.



Packaging & Shipping

 Top modular homes with garages factory for staff accommodation 2

Items&Project Show

Top modular homes with garages factory for staff accommodation 4Top modular homes with garages factory for staff accommodation 6Top modular homes with garages factory for staff accommodation 8Top modular homes with garages factory for staff accommodation 10Top modular homes with garages factory for staff accommodation 12Top modular homes with garages factory for staff accommodation 14Top modular homes with garages factory for staff accommodation 16

Company Information

   We Weifang Henglida Steel Structure Co.,Ltd.( Lida Group)  is one of the leading manufacturers of the prefabricated house, Flat Packed container house, steel villas, and steel structure warehouse in China. We have been doing well in this field for more than 20 years, and we have exported our products to more than 110 countries as well as our domestic market and the quality has been approved by CE, ISO9001:2000, BV and SGS.

                Top modular homes with garages factory for staff accommodation 18

 Top modular homes with garages factory for staff accommodation 20Top modular homes with garages factory for staff accommodation 22Top modular homes with garages factory for staff accommodation 24

 Top modular homes with garages factory for staff accommodation 26

Clients Visit

 Top modular homes with garages factory for staff accommodation 28

Our Services

1. Professional design and engineering team:

Full solution for site camp design. We could make the design for whole camp,warehouse,office and so on as per your requirement.



 2. Procurement and Manufacture for all material for prefabricated building:

We have a professional procurement team to make sure all the materials are with good quality. And our factory operation under ISO and EN1090 standard, to make sure the fabrication works with high technology.



3. Site management & Installation supervision support:

 We could dispatch our engineers to help for the installation supervision, you just need to prepare a team which know normal construction works will be OK.

Top modular homes with garages factory for staff accommodation 30

Lida Group has a team of professional designers and engineers. The team members have rich industry experience, advanced design concepts, and exquisite technology. The prefab house we produce is stable, safe and high-quality. Lida Group has professional design team and production team. Besides, we have advanced production technology and sophisticated production equipment. All this provides a strong guarantee for the high quality of prefab house.

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
