Wholesale portal frame warehouse Suppliers used as airport terminal and hangar 1
Wholesale portal frame warehouse Suppliers used as airport terminal and hangar 1

Wholesale portal frame warehouse Suppliers used as airport terminal and hangar

Inquiry
Company Advantages
1. Customers can choose different materials options for portal frame warehouse , including . This product is highly adaptable to dynamic loads
2. This product has revolutionized the transportation of goods and ultimately the international export market as turnaround time, theft, damage to goods and costs all went down. This product requires little maintenance, which helps save labor costs
3. portal frame warehouse is considered as the most promising to . This product requires an incredibly short installation time
4. Due to its , portal frame warehouse has been widely used in many applications such as . This product features level A fire protection grade
5. portal frame warehouse is provided with features of . This product has been certified under CE
Overview
Quick Details
Standard:
AiSi
Grade:
Steel
Place of Origin:
Shandong, China
Brand Name:
LIDA
Model Number:
S122
Type:
Light
Application:
Steel Fabricated House, warehouse/poultry building/chicken house/henhouse/workshop/hangar
Tolerance:
±1%
Product name:
steel structure hotel workshop
Keywords:
portable aircraft hangar
Main structure:
Q345 high strength H section steel
Wall and Roof:
Rock wool/Glass wool/EPS/PU sandwich panel
Certificates:
ISO 9001, CE EN1090
Service life:
70 years
Installation:
supervisor guiding is available
Door:
Sliding door or electricl rolling door
Span:
Single span 36m without central column
Supply Ability
Supply Ability:
50000 Square Meter/Square Meters per Month , Integrating cooperated factories capacity: 750000 sqm monthly

Wholesale portal frame warehouse Suppliers used as airport terminal and hangar 2

Product Description

 Conventional Customizable Prefabricated Building Steel Structure WarehouseWholesale portal frame warehouse Suppliers used as airport terminal and hangar 4

Materials:

1. The main frame (columns and beams) is made of welded H-style steel.

2. The columns are connected with the foundation by pre-embedding anchor bolt.

3. The beams and columns, beams and beams are connected with high intensity bolts.

4. The envelop construction net is made of cold form C-style purlins.

5. The wall and roof are made of color steel board or color steel sandwich panels, which are connected with the purlin by Self-tapping nails.

6. Doors and windows can be designed at anywhere which can be made into normal type, sliding type or roll up type with material of PVC, metal, alloy aluminium, sandwich panel and so on.



1. Steel Structure Buildings Introduction:

Light steel structure building is widely used as large factory, warehouse, workshops, bridges, stadiums and other buildings. Light steel structure warehouse building is a new type of building structure system, which is formed by the main steel framework linking up H-section, Z-section, and U-section steel components, roof and walls using a variety of panels and other components such as windows and doors.



2. Steel Structure Buildings Characteristics:

1.Wide span: single span or multiple spans, the max span is 36m without middle column
2.Low cost: unit price range from USD35/m2 to USD70/m2 according to customers request
3. Fast construction and easy installation
4. Long using lifespan: up to 50 years
5.Others: environmental protection, stable structure, earthquake resistance, water proofing, and energy conserving.

Wholesale portal frame warehouse Suppliers used as airport terminal and hangar 6



Wholesale portal frame warehouse Suppliers used as airport terminal and hangar 8



Wholesale portal frame warehouse Suppliers used as airport terminal and hangar 10



Wholesale portal frame warehouse Suppliers used as airport terminal and hangar 12



tructure     H-section steel Q345 steel H beam, Box column is also available
Welding Automatic Submerged Arc Welding
Rust removing Shot blasting
surface processing

twice primer and twice finish Alkyd Paint or hot dip

galvanized

High strength bolt Grade 10.9
Substructure     Angle brace L50x4,Steel Q235,Process and painting
Cross bracing Dia.20 round bar,Steel Q235, process and pre-galvanized
Tie bar

Dia.89*3 round pipe,Steel Q235 Process and painting

or pre-galvanized

Batter brace

Dia.12 round bar,Steel Q235 process and

pre-galvanized

Ordinary bolt Galvanized bolt
Roof       Purlin C channel or Z channel,steel Q235, galvanized
Roof panel

(50mm, 75mm, 100mm, 150mm) Sandwich panel or

corrugated GI color steel sheet

Transparent

skylight

1.2mm FRP
Accessories Sealant, self-tapping screw, etc.
Edge cover Made of color steel sheet
Gutter Made of steel sheet thickness 0.8mm, or PVC
Rinspout PVC pipe
Wall    Purlin C channel or Z channel, steel Q235, galvanized
Wall panel

(50mm, 75mm, 100mm, 150mm) Sandwich panel or

(0.4mm, 0.5mm, 0.6mm, 0.7mm) corrugated GI

color steel sheet

Accessories Sealant, self-tapping screw etc
Edge cover Made of GI color steel
Ventilator  unpowered axial-flow ventilator or monitor roof
Door & window  Electric rolling door/sliding door, PVC/Alu. alloy window
Crane  With or without crane, ranging from 5 tons to 20 tons



Related Products

Wholesale portal frame warehouse Suppliers used as airport terminal and hangar 14

Company Information


Wholesale portal frame warehouse Suppliers used as airport terminal and hangar 16Wholesale portal frame warehouse Suppliers used as airport terminal and hangar 18Wholesale portal frame warehouse Suppliers used as airport terminal and hangar 20Wholesale portal frame warehouse Suppliers used as airport terminal and hangar 22

FAQ


Wholesale portal frame warehouse Suppliers used as airport terminal and hangar 24

Q: Are you factory or trading company?

A: Our Lida Group have main factory named Weifang Henglida Steel structure Co., Ltd., which is in Weifang city. Qingdao Lida construction Facility Co., Ltd. is in Qingdao city. Shouguang Lida Prefab House Factory is in Shouguang city, all of them are in Shandong province.



Q: How about your production capacity?

A: Pre engineered steel structure building (warehouse/workshop/hangar/shed/high rise apartment): 50000 sqm monthly. Prefabricated house (portacabin/labor camp/site office): 100000 sqm monthly. Prefab affordable house (low cost family/residential/refugee): 4200 units monthly. Container house: 800 units monthly. Light steel villa: 10000 sqm monthly.



Q: How about your quality control?

A: We have got certificate ISO9001:2015, certificate CE EN 1090. Products processing through cutting, bending, welding, shot blasting, ultrasonic testing, packing, storing, loading to ensure no quality defects.



Q: Is third party inspection available?

A: SGS, BV, TUV, etc. are available, it is according to client requirement.



Q: How about your delivery time?

A: Generally within 30 days, it is according to order quantity, partial shipment is allowed for big order.



Q: What about the installation?

A: We'll provide the detailed installation drawing, supervisors guiding installation is available. We can do turnkey job for some kind of projects.



Q: How to ensure the product you supply is what we want exactly?

A: Before placing order, our sales and engineers team will provide you the suitable solution according to your requirements. Proposal drawing, Shop drawing, 3D drawing, Materials photos, Finished projects photos are available, which will help you understand the solution we provided deeply.Wholesale portal frame warehouse Suppliers used as airport terminal and hangar 26

The product makes buildings more energy efficient through proper, adequate insulation, and air sealing, which helps people save a lot of energy costs. This product has been designed to last for decades. The product has been widely known that it is able to last for a long time, which helps reduce maintenance and energy use in a building. This product has been designed to last for decades.
