Construction Site Labour Camp House

Home  > PRODUCT  > Camp House  > Construction Site Labour Camp House  >

20ft Modular Portable Office Prefabricated Flat Pack Container Labor Camp Building for Sales

这里可以自定义设置
20ft Modular Portable Office Prefabricated Flat Pack Container Labor Camp Building for Sales
B站不支持收货地址
B站不支持库存规格
Model
LD-CH-003
MOQ
6 sets
Payment
L/C, T/T
Place of Origin
Shandong,China
Brand
Lida
Delivery Time
25-30days
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障
该产品后台详情无内容

    MISSION

    prefab lowes modular portable flat pack australian standard homes prebuilt container house garage storage foldable

    Lida container houses include flat pack container house, foldable container house (folding container house), expandable container house, welding container house(customized container house)and modified shipping container house(converted shipping container house).

    Specification
    1) 20ft: 6055*2435*2896mm
    2) 40ft: 12192*2435*2896mm
    3) Roof Type: Flat roof with organized internal water draining design
    4) Storey: ≤3
    Design parameter
    1) Life span: up to 20years
    2) Floor Live load: 2.0KN/m2
    3) Roof Live load: 0.5KN/m2
    4) Wind load: 0.6KN/m2
    5) Earthquake-resistance: Grade 8, Fire-proof: Grade 4
    Wall panel
    1) Thickness: 75mm fiber glass sandwich panel, effective width: 1150mm
    2) Exterior steel sheet (standard configuration): Corrugated 0.4mm Aluminum-zinc color steel sheet, PE finishing coat, Color:
    white, Aluminum-zinc thickness≥40g/m2
    3) Insulation layer (standard configuration): 75mm Fiber glass, density≥50kg/m3, Fire-proof standard: grade A non-flambable
    4) Interior steel sheet(standard configuration): Flat 0.4mm Aluminum-zinc color steel sheet, PE finishing coat, Color: white,
    Aluminum-Zinc thickness≥40g/m2
    Roof system
    1) Steel frame & accessories: Main roof frame: cold formed steel, thickness=2.5mm, galvanized. with 4pcs galvanized lifting
    corners. Roof purlin: C80*40*15*2.0, galvanized. Q235B steel
    2) Roof panel: 0.4 or 0.5mm thickness Aluminum-zinc color steel sheet, PE finishing coat. Color: white, Aluminum thickness≥70g/m2,
    360° full connection
    3) Insulation: 100mm thickness Fiber glass with aluminum foil, Density=14kg/m3, Grade A fire-proof, nonflammable.
    4) Ceiling board: V-170 type, 0.5mm Aluminum-zinc color steel sheet, PE finishing coat. Color: white, Aluminum-zinc
    thickness≥40g/m2.
    5) Industrial socket: Fixed in explosion-proof box at the top beam of the short side, with 1 main power plug for power connection
    between containers
