Prefabricated House Villa Dormitory for Family or Labors

这里可以自定义设置
Prefabricated House Villa Dormitory for Family or Labors
B站不支持收货地址
B站不支持库存规格
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障
Overview
Quick Details
Warranty:
5 years
After-sale Service:
Onsite Installation
Project Solution Capability:
total solution for projects
Place of Origin:
Shandong, China
Brand Name:
LIDA
Model Number:
LIDA-PH001
Use:
Carport, Hotel, House, Office, Sentry Box,Guard House, Shop, Toilet
Product Type:
Sandwich Panel Houses
MATERIAL: LIGHT STEEL FRAME:
SANDWICH PANEL
Supply Ability
Supply Ability:
3000 Set/Sets per Week



Company Information



Weifang Henglida Steel Structure Co.,Ltd.( Lida Group) is one of the largest manufacturers of the prefabricated house, container house, steel villas, and steel structure warehouse in China.

We have specialized in this field for more than 20 years, and we have exported our products to more than 90 countries as well as our domestic market with ISO9001, CE,BV and SGS certification.

Lida Group is the main supplier of the series products for the Chinese key projects, such as the Olympic Sailing Center, Qingdao bay bridge ,Qingdao Channel Tunnel, etc.











Product Description



Material List For One Storey Prefabricated House
Main Steel Frame
 Steel  columnFabricated by Q235 Steel,   80*80 or 100*100 or 120*120 or 150*150 Square Tube, alkyd paiting, two primary painting, two finish painting.
Triangular Steel structure roofFabricated by Q235 Steel, C80, C100, C120, C140 Section steel,  alkyd paiting, two primary painting, two finish painting.
Roof PurlinFabricated by Q235 Steel, C80, C100, C120, C140 Section steel,  alkyd paiting, two primary painting, two finish painting.
Ordinary bolt4.8S,Zincification
Roof and Wall
Roof PanelInsulated Steel Sandwich Panel wall
Panel width: 950mm;
Thickness: 50-1200mm.
Powder coated Color steel on both sides:  0.4mm/0.5mm/0.6mm
Insulation: Polystyrene, Rockwool or Polyurethane
Density of Rockwool: 120Kg/m3
Density of Polystyrene: 12Kg/m3, 16KG/M3 20KG/M3
Density of Polyurethane: 40Kg/m3
 Wall Panel Insulated Steel Sandwich Panel wall
Panel width: 950mm;
Thickness: 50-1200mm.
Powder coated Color steel on both sides:  0.4mm/0.5mm/0.6mm
Insulation: Polystyrene, Rockwool or Polyurethane
Density of Rockwool: 120Kg/m3
Density of Polystyrene: 12Kg/m3, 16KG/M3 20KG/M3
Density of Polyurethane: 40Kg/m3
Edge cover0.4mmgalvanized Color steel , angle Alu.
Fasteners & accessoreisNails\glue ect
Ceiling+Flooring
Ceiling6mm gypsum board,with steel keel
Plywood18mm film faced plywood
 Floor feather 1.5mm  PVC floor leather
Door and window
Door External door: Insulated with opening dimension 950*2100mm, furnished with lock
with 3keys. Inner door: Insulated steel door.
 WindowPVC window witn 4mm glass, with screem
Electrical System
Electric cableHonyar brand, lighting 2.5m m2, aircondition: 4.0mm2, BV cable, solid core. Three diferent color
PVC wire ChannelHonyar brand
Lights  double tube fluorescent lamp, 220V,50-60HZ
SwitchesHonyar brand, Single Switch, with junction box
 Socket16A five hole univesal socket.
Power distribution cabinetHonyar brand, box+breakers+earth leakage protective device
Plumbing System and Rain Water Drainage System As per building design



Packaging & Shipping





Our Services



1. Provide best proposal as customers' request. including work out drawings and 3D pictures.



2. High quality facotory production with our more than 20 year working experience in this field.



3. Provide full set of construction drawings after shipment. of course including foundation construction drawing.



4. Send out engineers for installation guidance if need.

















FAQ



1. you are manufacture factory or trading company?

A: We are manufacture factory. Welcomed to visit our factory in the city of Weifang.

2.Why Choosing prefab house?

There are many advantages to modular camp construction for site camps including:

(1) Easy to assemble and disassemble for several times without damage.

(2) Could be lifted, moved , and combined freely.

(3) Heatproof and waterproof.

(4) Cost saving and convenient transportation (Each 4 container house can loaded in one standard container)

3. Why we trust you?

(1) We have already passed the ISO,CE,SGS,BV certification.

(2) We are one of the suppliers for Chinese government key project.

When comparing the cost and build time to a traditional home, this product will be less in both of these areas. Even applied in tough conditions, this product has an anti-deformation property. Choosing this product, a tiny home, is the best way to reduce the carbon footprint – and live a more eco-conscious lifestyle. Even applied in tough conditions, this product has an anti-deformation property.
