House design prefab low cost prefabricated house philippines in nepal 1

House design prefab low cost prefabricated house philippines in nepal 2

House design prefab low cost prefabricated house philippines in nepal 3

House design prefab low cost prefabricated house philippines in nepal 4

House design prefab low cost prefabricated house philippines in nepal 5

House design prefab low cost prefabricated house philippines in nepal 6

House design prefab low cost prefabricated house philippines in nepal

Inquiry

Write a Review

Overview

Quick Details

Warranty:: 3 years

After-sale Service:: Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement, NONE

Project Solution Capability:: graphic design, 3D model design, total solution for projects, Cross Categories Consolidation, NONE

Application:: Hotel

Place of Origin:: Shandong, China

Brand Name:: LIDA

Model Number:: LDAF 001

Use:: Hotel, House, Kiosk,Booth, Office, Sentry Box,Guard House, Shop, Toilet, Villa, affordable house, family house

Product Type:: Steel Structure

Design Style:: Modern

House design in nepal:: House design prefab low cost prefabricated house philippines in nepal

Keywords:: low cost prefab house

Structure frame:: cold formed galvanized light gauge steel, z275

Storey:: 1 or 2 storey are available

Wall panel:: ALC (Autoclaved Lightweight Concrete) panel, with paint

Roof panel:: glazed steel sheet tile

Ceiling insulation:: Fiber glass wool with aluminum foil

Service life:: at least 30 years

Installation:: supplier sending work team is available

Financing:: supplier could provide financing solution

Supply Ability

Supply Ability:: 2000 Unit/Units per Month low cost prefab house

House design prefab low cost prefabricated house philippines in nepal

Product Description

ALC panel specification

Light gauge steel structure frame production

Installation Photos

Detailed Specification

Main structure frame	C89, Q235 Steel, galvanized Cold Formed steel C channel
Roof and Wall system	1) Roof panel: 0.5mm thickness prepainted galvanized glazed steel tiles (glazed shape)
	2) Wall panel: 100mm ALC board, with paint
	3) Ceiling insulation: 50mm fiber glass wool with Aluminum foil
Ceiling	1) Ceiling for dry area: 6mm gypsum board or 12mm PVC board
Ceiling	2) Ceiling for wet area: 5mm calcium silicate board or 12mm PVC board
Door and Window	1) Entry door: Steel Security Door
	2) Inside door: Steel door or MDF door
	3) Window: PVC casement window or sliding window, 4mm single glazed, double glazed is also available, with mosquito screen
Electric system	1) Electric wire: lighting 2.5mm2, A/C: 4.0mm2, BV cable, solid core. Three different color
	2) Light: double tube LED light, dome lamp, outdoor waterproof light
	3) Switch: 1 gang and 2 gang Power distribution cabinet
	4) Socket: 5 holes universal socket
	5) Power distribution box: steel box+circuit breaker+earth leakage protective device
Plumbing	1) Closestool: ceramic one-piece closestool, with hand shower
	2) Washbasin: ceramic pedestal basin
	3) Shower: shower head, shower tray, water mixing valve
	4) Water pipe: inlet and outlet water pipe (PPR and UPVC)

ALC panel parameter

Thermal insulation

Low thermal conductivity, thermal conductivity ≤ 0.14W / m.k. Insulation is 10 times the cement concrete, performance of 125mm thick ALC panel equivalent to that of 370mm brick wall

Fire Performance

Wall TH (mm)	Fire resistance (hour)
75	>2
100	3.62
125	>4
150	>4

Sound insulation

wall thickness and surface processing method	Weighted volume (B)
100mm ALC panel + double side putty	40.8
125mm ALC panel + double side putty	45.1
150mm ALC panel + double side putty	46.6

Light weight and high strength

Density rating	B05	B06
Oven-dry density	≤525kg/m3	≤625kg/m3
Strength level	A3.5	A5.0

Low dry shrinkage rate

Material drying shrinkage rate of the good or bad depends on the inside the material after chemical reactions produced by the structure of the crystalline form, after using a special microscope observation proves that this product molecules is acicular crystal. Acicular crystals is the smallest drying shrinkage rate of material guarantee, the dry shrinkage rate of this product tested is 0.5 mm/m or less (standard: 0.8 mm/m or less).

Packaging & Shipping

Our Services

1) Professional sales team: all staff are bachelor and master, abroad team in Saudi Arabia, Qatar, Dubai, Kuwait, Maldives, Malaysia, Sri lanka, etc., provide the best communication.

2) Professional engineers team: all staff are master and doctor, provide the best engineering and solution.

3) Professional fabrication: all workers are through professional training, provide the quality guarantee products.

4) Professional installation team: supervisors guide installation from 2004 with rich experience.

5) Turnkey is also available for some projects.
