    Overview
    Quick Details
    Standard:
    AiSi, ASTM, bs, DIN, GB, JIS
    Grade:
    Q235 Q345B
    Place of Origin:
    Shandong, China
    Brand Name:
    Lida
    Model Number:
    LSS-007
    Type:
    Light
    Application:
    Steel Workshop
    Tolerance:
    ±1%
    H-section steel:
    Q345 steel 8mm to 10mm
    Welding:
    Automatic Submerged Arc Welding
    Rust removing:
    Sand blasting
    surface processing:
    Alkyd Paint or galvanized
    High strength bolt:
    Grade 10.9
    Angle brace:
    L50x4,Steel Q235,Process and painting
    Cross bracing:
    dia.20 round bar,Steel Q235, process and painting
    Tie bar:
    dia.89*3 round pipe,Steel Q235 Process and painting
    Batter brace:
    dia.12 round bar,Steel Q235 process and painting
    Ordinary bolt:
    Galvanized bolt
    Supply Ability
    Supply Ability:
    2000 Square Meter/Square Meters per Month steel structure warehouse

    Prefabricated steel structures commercial warehouse / steel metal buildings sheds construction 7



     Prefabricated steel structures commercial warehouse / steel metal buildings sheds construction 9



    1. Steel Structure Buildings Introduction:

    Light steel structure building is widely used as large factory, warehouse, workshops, bridges, stadiums and other buildings. Light steel structure warehouse building is a new type of building structure system, which is formed by the main steel framework linking up H-section, Z-section, and U-section steel components, roof and walls using a variety of panels and other components such as windows and doors.

    2. Steel Structure Buildings Characteristics:

    1.Wide span: single span or multiple spans, the max span is 36m without middle column
    2.Low cost: unit price range from USD35/m2 to USD70/m2 according to customers request
    3. Fast construction and easy installation
    4. Long using lifespan: up to 50 years
    5.Others: environmental protection, stable structure, earthquake resistance, water proofing, and energy conserving.



    Prefabricated steel structures commercial warehouse / steel metal buildings sheds construction 11



    Prefabricated steel structures commercial warehouse / steel metal buildings sheds construction 13







    3. Steel Structure Buildings Specification

    Main steel frame

    H-section steel



    Q345 steel 8mm to 10mm

    Welding



    Automatic Submerged Arc Welding

    Rust removing



    Sand blasting

    surface processing



    Alkyd Paint or galvanized

    High strength bolt



    Grade 10.9

    Supporting system

    Angle brace



    L50x4,Steel Q235,Process and painting

    Cross bracing



    dia.20 round bar,Steel Q235, process and painting

    Tie bar



    dia.89*3 round pipe,Steel Q235 Process and painting

    Batter brace



    dia.12 round bar,Steel Q235 process and painting

    Ordinary bolt



    Galvanized bolt

    Roof

    Purlin



    C160*60*2.5,steel Q235,Painting or galvanized

    Out-roof panel



    Sandwich panel or corrugated steel plate

    Transparent skylight



    6mm thick PVC

    Accessories



    Sealant,self-tapping screw, etc.

    Edge cover



    Made of color steel sheet thickness 0.5mm

    Gutter



    Made of steel sheet thickness 0.8mm, or PVC

    Rinspout



    dia.110 PVC

    Wall

    Purlin



    C160*60*2.5,steel Q235,paint



    Wall panel



    Sandwich panel or corrugated steel plate



    Accessories



    Sealant,self-tapping screw etc



    Edge cover



    Made of color steel sheet thickness 0.5mm

    Ventilator





    unpowered axial-flow ventilator or monitor roof

    Door &  window





    Rolling door/sliding door, PVC/alu. alloy window

    Crane





    With or without crane, ranging from 5 tons to 20 tons



    Finished projects

    We have recently finished the following project:

     1. 10000 M2 steel structure warehouse---Saudi Arabia

     2. 12050 M2 steel structure workshop--- The United Arab Emirates

     3. 14081 M2 steel structure supermarket--- The Republic of Djibouti

     4. 7200 M2 steel structure warehouse--- The United Kingdom of Great Britain and Northern Ireland

     5. 6000 M2 steel structure poultry---- The United Arab Emirates

     6. 3300 M2 pig shed---India

     7. 2250 M2 steel structure warehoue---Belgium

     8. 1500 M2 steel structure market---Ethiopia

     9. 702 M2 steel structure warehouse---Georgia

     10. 36 M2 garage---500 sets---Norway

     11. 20ft&40ft container house for U N project---Sudan

     12. 22 M2 temporary house---1000 sets---Philippines

     13. 200 M2 prefabricated labor camp---100 sets---Saudi Arabia

     14. 157 M2 prefabricated site office---36 sets---Malaysia

     15. 60 M2 prefabricated dormitory---2000 sets---Indonesia

    IMPORTANT

     If you really interested, please give me the following information:
    1. Dimension: Length, width, height, eave height, roof pitch, etc.
    2. Doors and windows: Dimension, quantity, where to put them.
    3. Local climate: Wind speed, snow load, etc.
    4. Insulation material: Sandwich panel or steel sheet.
    5. Crane beam: Do you need crane beam inside the steel structure?
    6. Is there any materials that are not allowed to import into the country where the structure is planning to use?
    7. If you have other requirements, such as fire proofing, isolated roof, etc, please also inform us.
    8. It's better if you have your own drawings or pictures. Please send them to us.



    Prefabricated steel structures commercial warehouse / steel metal buildings sheds construction 15





    Prefabricated steel structures commercial warehouse / steel metal buildings sheds construction 17





    Prefabricated steel structures commercial warehouse / steel metal buildings sheds construction 19





    Prefabricated steel structures commercial warehouse / steel metal buildings sheds construction 21





    Prefabricated steel structures commercial warehouse / steel metal buildings sheds construction 23



    Prefabricated steel structures commercial warehouse / steel metal buildings sheds construction 25



    Prefabricated steel structures commercial warehouse / steel metal buildings sheds construction 27

    Prefabricated steel structures commercial warehouse / steel metal buildings sheds construction 29



    Prefabricated steel structures commercial warehouse / steel metal buildings sheds construction 31

     Prefabricated steel structures commercial warehouse / steel metal buildings sheds construction 33





    The product has been already considered as an energy-efficient solution for the construction of modern buildings, thanks to its durability. This product is not prone to the effects of white ants. The product provides benefits for people by increasing comfort and well-being and helping to maintain the healthy air quality of buildings. This product is not prone to the effects of white ants.
