steel structure restaurant building

steel structure restaurant building

Add success, do you want to check your shopping cart?

Quick Details
AiSi, ASTM, bs, DIN, GB, JIS
Q345 low alloy steel
Place of Origin:
Shandong, China
Brand Name:
Model Number:
Steel Workshop
Processing Service:
Bending, Welding, Cutting, Punching
steel structure hotel building, prefabricated steel apartment building
steel metal frame structure
C.Z Shape Steel Channel
Wall and Roof:
Rock wool/Glass wool/EPS/PU sandwich panel
ISO 9001, CE EN1090
Surface treatment:
Hot Dip Gavalnized or Alkyd painting
Service life:
70 years
supervisor guiding is available
Sliding door or electricl rolling door
Single span 36m without central column
Product Certification certification
CE Certified.
Valid from 2017-02-08 until 2049-12-31
Supply Ability
Supply Ability:
50000 Square Meter/Square Meters per Month permanent building

Metal frame structure prefabricated steel apartment permanent building

Product Description



1, Prefabricated house is made of light steel as steel structure and steel plate/ sandwich panels/ALC Panel/Aluminium board/Concrete wall for wall and roof

2,The sandwich panels can be polystyrene, polyurethane, rock wool, and fiber glass sandwich panels for insulation, thickness could be 50,75,100,150,200mm

3,The steel structure main beams and contents are prefabricated in our workshop and connected by high-strength bolts, no need too much welding at site.

4,The steel structure building is a permanent building with the service life of over 70 years


1,Environment protective, no garbage caused

2,Doors, windows, and interior partitions can be flexibly fixed

3,Beautiful appearance, different colors for the wall and roof

4,Cost saving and transportation convenient

5,Anti-rust and normally more than 70years using lifespan

6,Safe and stable, can stand 8 grade earthquake

Technical parameter of standard prefabricated house:

1,Wind resistance:Customized, could resistant typhoon/hurricane

2,Earthquake resistance: grade 8

3,Live load capacity of roofing: normally 0.5kN/m², could be customized

4,External and internal wall heat transmission coefficient: 0.35Kcal/m2hc

5,Second floor load capacity: normally 150kg/m², could be customized

6,Live load of corridor: 2.0kN/m²

7,We can design and produce the house according to customer’s request

product display


prefabricated house





Related Products

Main structure

H-section steel

Q345 steel H beam, Box column is also available
Welding Automatic Submerged Arc Welding
Rust removing Shot blasting
surface processing twice primer and twice finish Alkyd Paint or hot dip galvanized
High strength bolt Grade 10.9
Substructure Angle brace L50x4,Steel Q235,Process and painting
Cross bracing Dia.20 round bar,Steel Q235, process and pre-galvanized
Tie bar Dia.89*3 round pipe,Steel Q235 Process and painting or pre-galvanized
Batter brace Dia.12 round bar,Steel Q235 process and pre-galvanized
Ordinary bolt Galvanized bolt
Roof Purlin C channel or Z channel,steel Q235, galvanized
Roof panel (50mm, 75mm, 100mm, 150mm) Sandwich panel or corrugated GI color steel sheet
Transparent skylight 1.2mm FRP
Accessories Sealant, self-tapping screw, etc.
Edge cover Made of color steel sheet
Gutter Made of steel sheet thickness 0.8mm, or PVC
Rinspout PVC pipe
Wall Purlin C channel or Z channel, steel Q235, galvanized
Wall panel (50mm, 75mm, 100mm, 150mm) Sandwich panel or (0.4mm, 0.5mm, 0.6mm, 0.7mm) corrugated GI color steel sheet
Accessories Sealant, self-tapping screw etc
Edge cover Made of GI color steel
Ventilator   unpowered axial-flow ventilator or monitor roof
Door & window   Electric rolling door/sliding door, PVC/Alu. alloy window
Crane   With or without crane, ranging from 5 tons to 20 tons


Company Information






Q: Are you factory or trading company?

A: Our Lida Group have main factory named Weifang Henglida Steel structure Co., Ltd., which is in Weifang city. Qingdao Lida construction Facility Co., Ltd. is in Qingdao city. Shouguang Lida Prefab House Factory is in Shouguang city, all of them are in Shandong province.


Q: How about your production capacity?

A: Pre engineered steel structure building (warehouse/workshop/hangar/shed/high rise apartment): 50000 sqm monthly. Prefabricated house (portacabin/labor camp/site office): 100000 sqm monthly. Prefab affordable house (low cost family/residential/refugee): 4200 units monthly. Container house: 800 units monthly. Light steel villa: 10000 sqm monthly.


Q: How about your quality control?

A: We have got certificate ISO9001:2015, certificate CE EN 1090. Products processing through cutting, bending, welding, shot blasting, ultrasonic testing, packing, storing, loading to ensure no quality defects.


Q: Is third party inspection available?

A: SGS, BV, TUV, etc. are available, it is according to client requirement.


Q: How about your delivery time?

A: Generally within 30 days, it is according to order quantity, partial shipment is allowed for big order.


Q: What about the installation?

A: We'll provide the detailed installation drawing, supervisors guiding installation is available. We can do turnkey job for some kind of projects.


Q: How to ensure the product you supply is what we want exactly?

A: Before placing order, our sales and engineers team will provide you the suitable solution according to your requirements. Proposal drawing, Shop drawing, 3D drawing, Materials photos, Finished projects photos are available, which will help you understand the solution we provided deeply.


The product helps create an adequate ventilation environment, reducing the potential for mold growth and buildup of allergens and other particulates. Its stainless steel materials can be reused after dismounted. The product is free of unpleasant smell and is skin-friendly. It does no harm to the human body while only improves the appearance of buildings. Its stainless steel materials can be reused after dismounted.
