The PNG Steel building, frame structure fabrication, garage, warehouse,storage,shed

这里可以自定义设置
The PNG Steel building, frame structure fabrication, garage, warehouse,storage,shed
B站不支持收货地址
B站不支持库存规格
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
LIDA
Model Number:
LD-S
Material:
Steel, light steel structure and sandwich panel
Use:
Carport, Hotel, House, Kiosk,Booth, Office, Sentry Box,Guard House, Warehouse, Workshop,Plant, Camp,warehouse,workshop,large factories etc.
keyword:
shed
Supply Ability
Supply Ability:
50000 Square Meter/Square Meters per Month

  The PNG Steel building, frame structure fabrication, garage, warehouse,storage,shed

Product Description

Main steel frame

H-section steel

Q345 steel 8mm to 10mm
WeldingAutomatic Submerged Arc Welding
Rust removingSand blasting
surface processingAlkyd Paint or galvanized
Intensive boltGrade 10.9
Supporting systemAngle braceL50x4,Steel Q235,Process and painting
Cross supportdia.20,Steel Q235, process and painting
Belt bardia.89*3,Steel Q235 Process and painting
Small bracedia.12,Steel Q235 process and painting
Ordinary boltGalvanized bolt
RoofPurlinC160*60*2.5,steel Q235,Painting or galvanized
Out-roof panelSandwich panel or corrugated steel plate
Transparent lighting panel6mm thick PVC
AccessoriesGlass glue,self-tapping screw etc.
Edge coverMade of color steel sheet thickness 0.5mm
GutterMade of steel sheet thickness 0.8mm
Rinspoutdia.110 PVC
WallPurlinC160*60*2.5,steel Q235,paint
 WallSandwich panel or corrugated steel plate
 AccessoriesGlass cement,self-tapping screw etc
 Edge coverMade of color steel sheet thickness 0.5mm
Ventilator Roof ventilator or nonitor top
Door &  window Rolling door/sliding door PVC/alu/steel window
Crane   With or without crane in 5 tons to 20 tons
FAQ

The max clear span: 36m

Size: customized

The max height: customized.

Steel Spec: Q345 or Q235

Main frame: hot roll H-style steel or welded H-style steel (square steel).

Wall/roof material: single galvanized color steel sheet or sandwich panel





Our Services
Designing drawing according to your request freely.
High quality process.
Detailed installation drawing supply
Experienced technician sending
Parts replaced free of charge Parts replaced free of charge

 If you really interested, please give me the following information:
1. Dimension: Length, width, height, eave height, roof pitch, etc.
2. Doors and windows: Dimension, quantity, where to put them.
3. Local climate: Wind speed, snow load, etc.
4. Insulation material: Sandwich panel or steel sheet.
5. Crane beam: Do you need crane beam inside the steel structure?
6. Is there any materials that are not allowed to import into the country where the structure is planning to use?
7. If you have other requirements, such as fire proofing, isolated roof, etc, please also inform us.
8. It's better if you have your own drawings or pictures. Please send them to us.


To customers, Lida Group aims to achieve meet their needs and create value. This product combines simplicity with utility. Lida Group provides quality products for nearly thousands of hotels in many countries around the world to enhance the user experience. This product combines simplicity with utility.
