    Overview
    Quick Details
    Warranty:
    3 years
    After-sale Service:
    Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement
    Project Solution Capability:
    graphic design, 3D model design, Cross Categories Consolidation
    Application:
    Hotel, Apartment, Office Building, Hospital, School, Mall, Sports Venues, Leisure Facilities, Supermarket, Warehouse, Workshop, Park, Farmhouse, Courtyard
    Place of Origin:
    Shandong, China
    Brand Name:
    LIDA
    Model Number:
    LDS
    Main frame:
    Q345B,H/I section beam
    Certificate:
    CE EN1090,BV,ISO9001
    Insulation:
    50mm,75mm,100mm
    Wall and roof:
    sandwich panel or corrugated sheet
    Max clear span:
    36m
    Max Life Time:
    more than 50 years
    Keywords:
    Light Steel Structure
    Supply Ability
    Supply Ability:
    500 Ton/Tons per Month

    wind-resistant prefabricated steel structure warehouse1 5

    Product Description

    Gable Frame Light Metal Building Prefabricated Industrial Steel Structure Warehousewind-resistant prefabricated steel structure warehouse1 7

    Materials:

    1. The main frame (columns and beams) is made of welded H-style steel.

    2. The columns are connected with the foundation by pre-embedding anchor bolt.

    3. The beams and columns, beams and beams are connected with high intensity bolts.

    4. The envelop construction net is made of cold form C-style purlins.

    5. The wall and roof are made of color steel board or color steel sandwich panels, which are connected with the purlin by Self-tapping nails.

    6. Doors and windows can be designed at anywhere which can be made into normal type, sliding type or roll up type with material of PVC, metal, alloy aluminium, sandwich panel and so on.



    1. Steel Structure Buildings Introduction:

    Light steel structure building is widely used as large factory, warehouse, workshops, bridges, stadiums and other buildings. Light steel structure warehouse building is a new type of building structure system, which is formed by the main steel framework linking up H-section, Z-section, and U-section steel components, roof and walls using a variety of panels and other components such as windows and doors.



    2. Steel Structure Buildings Characteristics:

    1.Wide span: single span or multiple spans, the max span is 36m without middle column
    2.Low cost: unit price range from USD35/m2 to USD70/m2 according to customers request
    3. Fast construction and easy installation
    4. Long using lifespan: up to 50 years
    5.Others: environmental protection, stable structure, earthquake resistance, water proofing, and energy conserving.

    wind-resistant prefabricated steel structure warehouse1 9

    wind-resistant prefabricated steel structure warehouse1 11



    tructure     H-section steel Q345 steel H beam, Box column is also available
    Welding Automatic Submerged Arc Welding
    Rust removing Shot blasting
    surface processing

    twice primer and twice finish Alkyd Paint or hot dip

    galvanized

    High strength bolt Grade 10.9
    Substructure     Angle brace L50x4,Steel Q235,Process and painting
    Cross bracing Dia.20 round bar,Steel Q235, process and pre-galvanized
    Tie bar

    Dia.89*3 round pipe,Steel Q235 Process and painting

    or pre-galvanized

    Batter brace

    Dia.12 round bar,Steel Q235 process and

    pre-galvanized

    Ordinary bolt Galvanized bolt
    Roof       Purlin C channel or Z channel,steel Q235, galvanized
    Roof panel

    (50mm, 75mm, 100mm, 150mm) Sandwich panel or

    corrugated GI color steel sheet

    Transparent

    skylight

    1.2mm FRP
    Accessories Sealant, self-tapping screw, etc.
    Edge cover Made of color steel sheet
    Gutter Made of steel sheet thickness 0.8mm, or PVC
    Rinspout PVC pipe
    Wall    Purlin C channel or Z channel, steel Q235, galvanized
    Wall panel

    (50mm, 75mm, 100mm, 150mm) Sandwich panel or

    (0.4mm, 0.5mm, 0.6mm, 0.7mm) corrugated GI

    color steel sheet

    Accessories Sealant, self-tapping screw etc
    Edge cover Made of GI color steel
    Ventilator  unpowered axial-flow ventilator or monitor roof
    Door & window  Electric rolling door/sliding door, PVC/Alu. alloy window
    Crane  With or without crane, ranging from 5 tons to 20 tons



    Related Products

    wind-resistant prefabricated steel structure warehouse1 13

    Company Information


    wind-resistant prefabricated steel structure warehouse1 15wind-resistant prefabricated steel structure warehouse1 17wind-resistant prefabricated steel structure warehouse1 19wind-resistant prefabricated steel structure warehouse1 21

    FAQ


    wind-resistant prefabricated steel structure warehouse1 23

    Q: Are you factory or trading company?

    A: Our Lida Group have main factory named Weifang Henglida Steel structure Co., Ltd., which is in Weifang city. Qingdao Lida construction Facility Co., Ltd. is in Qingdao city. Shouguang Lida Prefab House Factory is in Shouguang city, all of them are in Shandong province.



    Q: How about your production capacity?

    A: Pre engineered steel structure building (warehouse/workshop/hangar/shed/high rise apartment): 50000 sqm monthly. Prefabricated house (portacabin/labor camp/site office): 100000 sqm monthly. Prefab affordable house (low cost family/residential/refugee): 4200 units monthly. Container house: 800 units monthly. Light steel villa: 10000 sqm monthly.



    Q: How about your quality control?

    A: We have got certificate ISO9001:2015, certificate CE EN 1090. Products processing through cutting, bending, welding, shot blasting, ultrasonic testing, packing, storing, loading to ensure no quality defects.



    Q: Is third party inspection available?

    A: SGS, BV, TUV, etc. are available, it is according to client requirement.



    Q: How about your delivery time?

    A: Generally within 30 days, it is according to order quantity, partial shipment is allowed for big order.



    Q: What about the installation?

    A: We'll provide the detailed installation drawing, supervisors guiding installation is available. We can do turnkey job for some kind of projects.



    Q: How to ensure the product you supply is what we want exactly?

    A: Before placing order, our sales and engineers team will provide you the suitable solution according to your requirements. Proposal drawing, Shop drawing, 3D drawing, Materials photos, Finished projects photos are available, which will help you understand the solution we provided deeply.wind-resistant prefabricated steel structure warehouse1 25

    The product has been already considered as an energy-efficient solution for the construction of modern buildings, thanks to its durability. This product is characterized by its ventilation design. With its reasonable inner structure, the product is robust enough to withstand most of the extreme weather conditions, protecting the building. This product is characterized by its ventilation design.
